30055
10 Amp to 50 Amp |
Cycles On-Off when load is excessive.
Stud Terminals
Breaker Type Type I
Voltage 6-12V DC
Amperes 10-50 Amp
Terminals Two threaded studs with nuts.
Terminal Size 10-32 Thread
Housing Style Plated steel case
With bracket Mounting.
|
10 to 40 Amp
Cost $12.00 ea.
50 Amp
Cost $13.75 ea.
|
30056
6 Amp to 50 Amp |
Cycles On- Off when load is excessive.
Stud Terminals
Breaker Type Type I
Voltage 6-12V DC
Amperes 10 - 50 Amp
Terminals Threaded Studs(2) With Nut Terminal Size 10-32 Thread
Housing Style Plated steel case
No
bracket Mounting Method
Snaps into 30090 Series
Mounting
Bracket
|
10 to 40 Amp
Cost $11.75 ea.
50 Amp
Cost $18.65 ea.
|
|
|
|
30171
10 Amp to 30 Amp
Soon to be NLA |
24 Volt Type I Circuit Breaker
Cycles On-Off when load is excessive.
Stud Terminals
Breaker Type Type I
Continuous Auto Reset
Voltage 6-24V DC
Amperes 10-30 Amp
Terminals Two threaded studs with nuts.
Terminal Size 10-32 Thread
Housing Style Plated steel case
With Out bracket Mounting. |
Your Cost
10 Amp to 30 Amp
Cost $12.75 ea.
|
30172
15 Amp to 30 Amp
Soon to be NLA |
24 Volt Type I Circuit Breaker
Cycles On-Off when load is excessive.
Stud Terminals
Breaker Type Type I
Continuous Auto Reset
Voltage 6-24V DC
Amperes 15-30 Amp
Terminals Two threaded studs with nuts.
Terminal Size 10-32 Thread
Housing Style Plated steel case
With bracket Mounting. |
Your Cost
15 Amp to 30 Amp
Cost $9.75 ea.
|
30407
15 Amp to 40 Amp |
6-12 Volt Type III Circuit Breaker
Cycles Off when load is excessive.
Manual Reset
Stud Terminals
Breaker Type Type III
Voltage 6-12V DC
Amperes 10-40 Amp
Terminals Two threaded studs with nuts.
Terminal Size 10-32 Thread
Housing Style Plastic Case
With bracket Mounting. |
Your Cost
10 Amp to 40 Amp
Cost $15.75 ea. Soon to be NLA
|
CB123NB 15 TO 50 Amp |
6-32 Volt Type III Circuit Breaker
Cycles Off when load is excessive.
Manual Reset
Stud Terminals
Breaker Type Type III
Voltage 6-32 Volt DC
Amperes 15 - 50 Amp
Terminals Two threaded studs with nuts.
Terminal Size 10-32 Thread
Housing Style Plastic Case
No Mounting Bracket.
May Replace Cole Hersee 30406 Series |
Your Cost
15 To 50 Amp
Cost $12.50 ea.
|
CB123 10 TO 50 Amp |
6-32 Volt Type III Circuit Breaker
Cycles Off when load is excessive.
Manual Reset
Stud Terminals
Breaker Type Type III
Voltage 6-32 Volt DC
Amperes 10 - 50 Amp
Terminals Two threaded studs with nuts.
Terminal Size 10-32 Thread
Housing Style Plastic Case
With bracket Mounting. |
Your Cost
10 To 50 Amp
Cost $12.50 ea.
|
86099-2
shown
|
Circuit Breaker Buss Bar
Junction Circuit Breakers Together For 1 Battery Source,
22.9mm - .91" Between Contact Points |
Your Cost
2 = $4.50
3 = $6.50
4 = $4.95
5 = $4.75
|
CBCB-B
CBCB-R |
Protection For Circuit Breaker Studs
Causing Electrical Shorts
Circuit Breaker Cover Boot Come In Red & Black |
Your Cost
Black
$5.85 ea.
Your Cost
Red
$2.50 ea.
|
CB222
10 Amp to 30 Amp |
Bussmann Type II Circuit
Breaker
Circuit will stays open until
Battery Current is Removed.
Breaker Type II
1/4" (.250") Blade Terminals
Plugs in to ATC / ATO Fuse Panels
Or In Line Connector
Voltage 6-12V DC
CB227-10
CB227-15
CB227-20
CB227-30 |
Your Cost
10
Amp to 30 Amp
Cost $7.50 ea.
|
CB223
10 Amp to 30 Amp |
Bussmann Push To Reset Type Circuit
Breaker
Circuit will stays open when the load is
Excessive Manual Reset Button.
Breaker Type III
1/4" (.250") Blade Terminals
Certifications: SAE J553
Plugs in to ATC / ATO Fuse Panels
Or In Line Connector
Voltage 6-28V DC
CB223-10
CB223-15
CB223-20
CB223-30 |
Your Cost
10
Amp to 30 Amp
Cost $10.75 ea.
|
CB227
10 Amp to 30 Amp |
Bussmann Push To Reset Type Circuit
Breaker
Circuit will stays open when the load is
Excessive Manual Reset Button.
Breaker Type III
1/4" (.250") Blade Terminals
Plugs in to ATC / ATO Fuse Panels
Or In Line Connector
Voltage 6-12V DC
CB227-10
CB227-15
CB227-20
CB227-30
|
Your Cost
10
Amp to 30 Amp
Cost $9.75 ea.
|
CB1911-30
30 Amp Type I
|
Bussmann 30A Auto Reset Type I Circuit
Breaker
Circuit will Trip When the load is
Excessive and Auto Reset.
Breaker Type I
5/16" (.315") Blade Terminals
Plugs in to Max Fuse Slot
Or In Line Fuse Connector
Voltage 6-24V DC
19430-01M
|
Your Cost
30 Amp
Cost $12.50 ea.
|
15600-06-20
6 Circuit
ATO/ATC Fuse Panel |
ATO/ATC FUSE BLOCK 6 FUSE CIRCUIT
ATC & ATO Bladed Fuses
6 Output Connections: 6.3mm Blades
Input Connection: 10-32 Stud
25 Amp Max Per Each Fuse.
Bussmann Replaces 15600-06-00, 15600-0610
Cole Hersee 46377-6
|
|
15600-08-20
8 Circuit
ATO/ATC Fuse Panel
|
ATO/ATC FUSE BLOCK WITH 8 TERMINALS
ATC & ATO Bladed Fuses
8 Output Connections: 6.3mm Blades
Input Connection: 10-32 Stud
25 Amp Max Per Each Fuse.
Bussmann 15600-08-00,15600-0810
Cole Hersee 46377-8 |
|
15600-06-11
6 Circuit With Ground Pad
ATO/ATC Fuse Panel |
ATO/ATC FUSE BLOCK 6 FUSE CIRCUIT
ATC & ATO Bladed Fuses
6 Output Connections: 6.3mm Blades
With 1/4" Grounding Pad Terminals
Input Connection: 10-32 Stud
25 Amp Max Per Each Fuse.
Replaces Bussmann 15600-0611, 15600-0621
|
|
15600-08-11
8 Circuit With Ground Pad
ATO/ATC Fuse Panel |
ATO/ATC FUSE BLOCK 8 FUSE CIRCUIT
ATC & ATO Bladed Fuses
8 Output Connections: 6.3mm Blades
With 1/4" Grounding Pad Terminals
Input Connection: 10-32 Stud
25 Amp Max Per Each Fuse.
Replaces Bussmann15600-08-10, 15600-0811
15600-0821, Cole Hersee 46379-8
"Less Fuses & Circuit Breaker "
|
|
FHWPATC |
ATO/ATC WATERPROOF FUSE HOLDER
Accepts ATC Automotive Fuses
Waterproof Plastic Body with Mounting Hole
Locking Protective Cover
5"
12 Gauge Leads
Maximum 30 Amp Fuse
We can Supply You The Components to
Assemble your own
ATC / ATO Waterproof Holders
|
|
ATO
/ATC FUSE BLOCK WITH LEADS
FBATC-4C
|
ATO/ATC FUSE BLOCK FOR 4 FUSES
COMES WITH 1-12 GAUGE 12" BATTERY INPUT
4-12 GAUGE 12" LEADS ON THE FUSED SIDE
These Fuse Blocks Housings can be stacked.
30 Amp Max Per Each Fuse.
|
|
FBATM-4C
4 ATM Fuse Circuit
|
ATM MINI FUSE BLOCK FOR 4 FUSES
With Clear Cover
Input terminal rating: #10-32 threaded stud
(100A max)
Output terminals 1/4" (.250) Push On Blade
Maximum rating 30A per circuit
Fuse Type ATM Mini (not supplied)
Voltage: Max 32 volts DC
Operating Temperature:
-13°F to 85° F (-25°C to 85° C)
W 3.346"
L 2.48"
H 1.398"
|
|
FBATM-10C
10 ATM Fuse Circuit |
ATM MINI FUSE BLOCK FOR 10 FUSES
With Clear Cover
Input terminal rating: #10-32 threaded stud
(100A max)
Output terminals 1/4" (.250) Push On Blade
Maximum rating 30A per circuit
Fuse Type ATM Mini (not supplied)
Voltage: Max 32 volts DC
Operating Temperature:
-13°F to 85° F (-25°C to 85° C)
W 3.346"
L 3.75"
H 1.398"
|
|
ATO/ATC FUSE BLOCK
FBATC-4
|
ATO/ATC FUSE BLOCK FOR 4 FUSES
COMES WITH 8 TERMINALS
These Fuse Blocks Housings can be stacked.
20 Amp Max Per Each Fuse.
COMES WITH TERMINALS FOR 16-14 GA Wire
Pack-Con Series III
Terminal ONLY # 12020334 18-20 ga.
Terminal ONLY # 12020321 16-14 ga.
Terminal ONLY # 12020400 12 ga. |
|
FBATC-6C |
ATO/ATC FUSE BLOCK FOR 6 FUSES
COMES WITH COVER
(Less Fuses )
With 8 Gauge Battery Feed Wire
3/8" Stud
20 Amp Max Per Each Fuse.
|
|
5025
6 Circuit Fuse Panel
|
ATO/ATC FUSE BLOCK WITH 6 CIRCUIT
WITH POSITIVE & NEGATIVE BUS TERMINALS
Marine Grade
20 Write-On Labels Included
30 Amp Max Per Each Fuse.
Max Per Panel 100 Amps.
32V DC Maximum Voltage.
|
|
5026
12 Circuit Fuse Panel |
ATO/ATC FUSE BLOCK WITH 12 CIRCUIT
WITH POSITIVE & NEGATIVE BUS TERMINALS
Marine Grade
20 Write-On Labels Included
30 Amp Max Per Each Fuse.
Max Per Panel 100 Amps
32V DC Maximum Voltage
|
|
880089S
600 Amp Fuse Panel
|
|
|
30090-2
shown |
30090
Circuit Breaker Mounting Brackets
Available For
2 to 8 Snap In Circuit breakers
|
Your Cost
-2 = $5.25
-3 = $5.75
-4 = $5.95
-6 = $6.25
-8 = $6.75 |
|
AMG
Type Fuses
125
Amp TO 500 Amp |
Your
Cost
$16.50 ea. |
AMGFH |
|
|
|
ANL
Type Fuses
80 to 600 Amp fuses |
Your
Cost
$42.50 ea. |
|
ANN
Fast Acting Type Fuses
200, 400 & 600 Amp
|
Your
Cost
$60.50 ea. |
ANLFH
|
Anl
Type Fuse Holders
All ANL Type Fuses |
Your
Cost
$29.80 |
ANLFHC
|
Anl
Type Fuse Holder
With 2 Boots and Fuse Cover
All ANL Type Fuses |
Your
Cost
$22.50 |
AMIFH
|
|
|
|
AMI / MIDI Type Fuses
30
Amp To 200 Amp
|
Your
Cost
$14.50
|
CB174 8 To 30 Amp |
Manual Reset Button Circuit Breaker.
Breaker Type III
1/4" Blade Terminals
7/16"- 28 Threaded Neck
Panel Mount Circuit Breaker
Threaded Neck and Retaining Nut
Voltage 6-32V DC
Bussmann CB174 Series Breakers
Available in 8,10,15,20,30 Amp
6-32 VDC volts,Type: Type III - Manual Reset,
Click Here for a Drawing.
|
Your Cost
$12.50 ea.
|
CB174B 10 To 20 Amp |
Manual Reset Button Circuit Breaker.
Breaker Type III
90° Screw Terminals
8-32 Screws on the 10 Amp to 30 Amp.
7/16"- 28 Threaded Neck
Panel Mount Circuit Breaker
Threaded Neck and Retaining Nut
Voltage 6-32V DC
Bussmann CB174B Series Breakers
Available in 10,15,20 Amp
6-32 VDC volts,Type: Type III - Manual Reset,
Click Here for a Drawing.
|
Your Cost
$12.50 ea.
|
CBW58
30, 40, & 50 Amp |
Optifuse Manual Reset Button Circuit Breaker.
Breaker Type III
90° Screw Terminals
8-32 Screws on the 40 Amp to 50 Amp.
7/16"- 28 Threaded Neck
Panel Mount Circuit Breaker
Threaded Neck and Retaining Nut
Voltage 6-32V DC
Can Replace the
Bussmann CB174B Series Breakers
Available in 30, 40, & 50 Amp
6-32 VDC volts,Type: Type III - Manual Reset,
Click Here for a Drawing.
|
Your Cost
$14.50 ea.
|
1648-009-060-60
|
Mechanical Products Manual Reset Button Circuit Breaker.
60 Amp Breaker Type III
90° Screw Terminals
10-32 Screws
7/16"- 28 Threaded Neck
Panel Mount Circuit Breaker
Threaded Neck and Retaining Nut
Voltage 6-50V DC
60 Amp
6-50 VDC volts,Type: Type III - Manual Reset
1648-009-060-60
1648-009-060 60A |
Your Cost
$23.50 ea.
|
CB174C |
Clear Cover For The CB174 Series
Manual Reset Button Circuit Breaker.
For 7/16"- 28 Threaded Neck
|
Your Cost
$2.75 ea.
|
|
Klixon CDA5
Circuit Breaker, Automatic Reset
.250 Long
8-32 Studs
0-30 VDC
5 Amp
Type I - Continuous Auto Reset
Weatherproof Circuit Breaker
References:
CDA5
Soon to be NLA
|
Your Cost
$46.50
|
|
Klixon SDLA Series
Circuit Breaker
Automatic Reset
1/4" .250
Studs
0-30 VDC
40 Amp to 150 Amp
Type I - Continuous Auto Reset
Weatherproof Circuit Breaker
Replaces: CDLA Series Breakers
CDLA40 / SDLA40
CDLA50 / SDLA50
CDLA60 / SDLA60
CDLA70 / SDLA70
CDLA80 / SDLA80
CDLA120 / SDLA120
CDLA135 / SDLA135
CDLA150 / SDLA150
|
Your Cost
$70.50
|
Rear View
|
Click Here For Drawing
Klixon SDLM Series
Circuit Breaker
Manual Reset Type III Breaker
1/4" .250
Studs
0-30 VDC
40 Amp to 150 Amp
Replaces: CDLM Series Breakers
CDLM40 / SDLM40
CDLM50 / SDLM50
CDLM60 / SDLM60
CDLM80 / SDLM80
CDLM105 / SDLM105
CDLM120 / SDLM120
CDLM135 / SDLM135
CDLM150 / SDLM150 |
Your Cost
$102.50
|
|
Klixon CDM Series Breakers
Circuit Breaker, Manual Reset
8-32
Studs
0-30 VDC / 120 VAC
5 Amp To 40 Amp
Type III - Manual Reset
6.3mm Mounting Holes-40mm Center To Center
Replaces Klixon CM Series Breakers
CM5 / CDM5
CM8 / CDM8
CM10 / CDM10
CM20 / CDM20
CM25 / CDM25
CM30 / CDM30
CM35 / CDM35
CM40 /CDM40
|
|
|
Klixon 7851-18 Series Circuit Breaker
Manual Reset Circuit Breaker
10-32"
Studs
0-30 VDC / 120 VAC
50 & 60 Amp
Type III - Manual Reset
Weatherproof
Applications:
Marine , Military , RV
7851-18-50
7851-18-60
Soon to be NLA
|
|
|
Klixon 7851-37 Series Circuit Breaker
Manual Reset Circuit Breaker
10-32"
Studs
0-30 VDC / 120 VAC
40, 50 & 60 Amp
Type III - Manual Reset
Weatherproof
Applications:
Marine , Military , RV
7851-37-40
7851-37-50
7851-37-60
Soon To Be NLA
|
|
|
Klixon 7855-6 Series Circuit Breaker
Manual Reset Circuit Breaker
3/8-24"
Studs
0-30 VDC / 120 VAC
200 Amp
Type III - Manual Reset
Weatherproof
Applications:
Marine , Military , RV
|
|
CB181-Series
Available 70, 80, 90, 100,120,10 Amp
|
HI-AMP Circuit Breakers
Auto Circuit Breaker.
Available 70, 80, & 100 150 Amp
6-48VDC
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
CB181F- 60 Series
CB181F- 70 Series
CB181F- 80 Series
CB181F- 90 Series
CB181F- 100 Series
CB181F - 120 Series
CB181F- 150 Series
Click Here or on the Circuit
Breaker Image for a Line Drawing. |
Your Cost
$49.50
|
153 Series
Available From 50 to 150 Amp
353 200 Amp Series
3/8-16" Studs
|
OPTIFUSE HI-AMP Circuit Breakers
Manual Type III Reset
Switch able
Circuit Breaker.
Waterproof and Ignition Protected
Available From 30 to 200 Amp
6-48VDC 153 Series Breakers 30-150 Amp with 1/4-28" Stud Size
353 Series Breaker 200 Amp with 3/8-16" Studs
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
Click Here or on the Circuit
Breaker Information and Drawing.
|
Your Cost
30-150 Amp
$56.50
Your Cost
200 Amp
$58.50
|
CB185 Series
Available From 30 to 150 Amp |
HI-AMP Circuit Breakers
Manual Type III Reset
Switch able
Circuit Breaker.
Available From 30 to 150 Amp
6-48VDC
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
Click Here or on the Circuit
Breaker Image for a Line Drawing.
|
Your Cost
$69.50
|
19M-P10 Series
200 Amp
|
HI-AMP Type III Circuit Breakers
19M-P10-B-200-01 Manual Reset
200 Amp
Circuit Breaker.
30 Volt Max
Conforms to Mil-STD-202 for corrosion, humidity and shock protection.
Mil-STD-204 for vibration protection.
1/4-28" Stainless Steel Stud & Nuts
SAE J1171 compliant, ignition protected
Interrupt capacity SAE J1625, ABYC-E11
IP67 dust and waterproof rated
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
Click Here or on the Circuit
Breaker Image
for a Line Drawing.
|
Your Cost
$89.50
|
171-S2 Series
300 Amp
|
HI-AMP Type I Circuit Breakers
Auto Reset 300 Amp. 14 Volt Only
171-S2-300-2
Conforms to Mil-STD-202 for corrosion, humidity and shock protection.
Mil-STD-204 for vibration protection.
3/8-24" Stainless Steel Stud & Nuts
SAE J1171 compliant, ignition protected
Interrupt capacity SAE J1625, ABYC-E11
IP67 dust and waterproof rated
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
Click Here or on the Circuit
Breaker Image
for a Line Drawing.
|
Your Cost
$76.50
|
174-S2 Series
250 Amp
|
HI-AMP Type III Circuit Breakers
Manual Reset 250 Amp. 14 Volt Only
174-S2-250-2
Conforms to Mil-STD-202 for corrosion, humidity and shock protection.
Mil-STD-204 for vibration protection.
3/8-24" Stainless Steel Stud & Nuts
SAE J1171 compliant, ignition protected
Interrupt capacity SAE J1625, ABYC-E11
IP67 dust and waterproof rated
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
Click Here or on the Circuit
Breaker Image
for a Line Drawing.
|
Your Cost
$66.50
|
174-S3 Series
Available in 175 Amp
|
HI-AMP Type III Circuit Breakers
Manual Reset 175 Amp.
Conforms to Mil-STD-202 for corrosion, humidity and shock protection.
Mil-STD-204 for vibration protection.
3/8-24" Stainless Steel Stud & Nuts
SAE J1171 compliant, ignition protected
Interrupt capacity SAE J1625, ABYC-E11
IP67 dust and waterproof rated
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
Click Here or on the Circuit
Breaker Image
for a Line Drawing. |
Your Cost
$63.50
|
175-S3 Series
Available in 120, 150, 175 & 200 Amp
|
HI-AMP Type III Circuit Breakers
Manual Reset
Switch able
Circuit Breaker.
Available in 120,150,175 & 200 Amp.
The 120,150, Amp Breakers 48 Volt Max
The 175, 200 Amp Breakers 30 Volt Max
Conforms to Mil-STD-202 for corrosion, humidity and shock protection.
Mil-STD-204 for vibration protection.
3/8-24" Stainless Steel Stud & Nuts
SAE J1171 compliant, ignition protected
Interrupt capacity SAE J1625, ABYC-E11
IP67 dust and waterproof rated
Applications: Used in auxiliary accessory circuits where you
need hi-amp current & protection too. Cars,Trucks, Buses,
RV's and Marine applications.
Click Here or on the Circuit
Breaker Image
for a Line Drawing.
|
Your Cost
$62.50
|
