Continuous Duty Relays & Intermittent Duty Relays

Click On Relay
For More Information


SAW-4201 Starter Relay 15-79 12 Volt  100 Amp Intermittent Duty Rating.

15-79
SAW-4201
Your Cost
$46.90

AMETEK / Prestolite
12 Volt DC Applications:
Starter Relay
3 Terminal Intermittent Duty
Grounded Base
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Rating 100 Amp
References:
Caterpillar 59925
Chrysler 1889797
Fenner Stone E3-1001-00,
Monarch 3427 Prestolite 15-226,
15-60, 15-8, SAW4201, SAW-4201
Ramsey Winch 20042



Click On Relay
For More Information


SAW-4204 Starter Relay 15-123 12 Volt  100 Amp Intermittent Duty Rating.

15-123
SAW-4204
Your Cost
$57.50

AMETEK
12 Volt DC High Current Applications:
Starter Relay , Power up relays to remove loads from Ignition Switches.
Grounded Base
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Intermittent Duty Rating 100 Amp
Prestolite SAW4204
Replaces Numbers Cole Hersee 24037
Onan 307-0025, 307-025
Prestolite 15-11, 15-16, 15-71, 15-247 SAW-4204
SAW4204, SAW4215, SAW-4215
Yale 61633200


Click On Relay
For More Information

12 Volt 100 Amp Continuous Duty
15-132
SAS-4201

Your Cost
$57.50
AMETEK 12 Volt DC High Current Applications:
Power up relays to remove loads from Ignition Switches, Electric Cooling Fans,
and ,many more applications.
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 100 Amp
Prestolite SAS4201
Can Substitute for Trombetta
974-1215-011,974-1215-011-09

Click On Relay
For More Information


12 Volt Relays 200 amp Forward & Reverse Systems Winches, Golf Carts

15-133
SAS-4202

Your Cost
$65.50



AMETEK
12 Volt DC High Current Applications:
Power up relays to remove loads from Ignition Switches, Electric Cooling Fans,
and ,many more applications.
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Silver
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 200 Amp
SAS4202 / 15-108

Click On Relay
For More Information

12 Volt 100 Amp 3 Terminas Continuous Duty Grounded Case
15-139
SAS-4208

Your Cost
$58.50


12 Volt Universal Application:
Power Up Relays to remove loads from Ignition Switches, Electric Cooling Fans,
and much more.
Ground Case Circuit
Normally Open Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 100 Amp
Replaces Cole Hersee 24106,
Prestolite , SAS-4208
White Rodgers W/R 70-914
70-111225-5A


Click On Relay
For More Information

24 Volt Forward & Reverse Systems Winches, Golf Carts

15-141
SAS-4401

Your Cost
$84.50



AMETEK 24 Volt DC Universal Applications
Power Up Relays,Pump Motors ,High Current Utility Vehicles, Winches, Lift Trucks,
Snow Plows etc.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Silver
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Rating 200 Amp
May be used to replace Prestolite
15-196, 15-204, 15-310, SAS4401, SAS-4408, SAS-5401
, SAS5401
SAS5401A
Monarch/Bucher 3341,
GM 6960296
Yale 501270302, 65640400

Click On Relay
For More Information

Ametek Relay 15-212 Ground Activated 12 Volt 100 Amp Relay.
15-212
SAW-4211

Your Cost
$58.50
AMETEK / PRESTOLITE
12 Volts
Intermittent Duty

Ground Activated Circuit
Contacts :Copper
5/16-24 Threaded Motor & Battery Studs
10-32 Threaded Excitation Terminal
Curved Mounting Base with 7mm x 14mm Mounting Slots-43mm Apart
100 Amp Current Rating
References:
Fenner Stone 13-06319091-01,
E2-2001-00

Prestolite SAW4211 / SAW-4211
Click On Relay
For More Information

Monarch 3336, 904-1243-610-15 Prestolite SAW-4218
15-254
SAW-4218
Your Cost
$60.50
AMETEK / PRESTOLITE
12 Volt DC Special Applications
Curved Mounting Base with 5.6mm x 7mm Oval Mounting Holes-49mm Apart.
Ground Activation Circuit
Normally Open Circuitry SPST
Contacts : Copper
Housing : plated steel
Voltage Rating 12V DC
1 Terminal copper; 10-32 thread
and 2 5/16"-24 thread.
Intermittent Duty Rating 100 Amp

Monarch 3336, 904-1243-610-15
Prestolite SAW4218 , SAW-4218
Click On Relay
For More information

SAZ-4201E 12 Volt  100 Amp Relay
15-268
SAZ-4201E
Your Cost
$38.50
Ametek, Prestolite, Solenoid
12 Volt 3 Terminal Grounded Base
100 Amp Rating,Intermittent Duty Relay.
2-5/16-18 Battery & Motor Studs
1-10-32 Excitation Stud
Contacts : Copper
Sealed Case
John Deere AM30182
Prestolite 15-306, SAZ4201AD
SAZ-4201AD, SAZ4201E
Click On Relay
For More Information

24 Volt 100 Amp Continuous Duty Relay GM Part Number 672758 / SAS4410 / SAS-4410
15-269
SAS-4410
Your Cost
$56.25
AMETEK 24 Volt DC Universal Applications
Power Up Relays,Pump Motors ,High Current Utility Vehicles, Winches, Lift Trucks,
Snow Plows etc.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Copper
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Rating 100 Amp
Can be used to in place of Prestolite
SAS4410 / SAS-4410

General Motors 672758

SAZ4401G, 24 Volts Ametek / Prestolite 3 Terminal 100A H.D.Intermittent Duty 15-286
15-286
SAZ-4401G
Your Cost
$90.5
0

24 Volts Ametek / Prestolite
3 Terminal
Insulated Ground Circuit
100 Amp H. D. Intermittent Duty
Curved 2.22 Mounting Base
SPST Copper-Cadmium
Plastic Case
(2) 5/16-24 Load Terminals
(1) 10-32 Coil Terminals
SAZ-4401G, SAZ4401G
Click On Relay
For More information

SAZ-4201AC 12 Volt  100 Amp Relay
15-298
SAZ-4201AC
Your Cost
$43.50

AMETEK 12 Volt DC
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; (1) 10-32 thread
and (2) 5/16"-18 thread.
Intermittent Duty Rating 100 Amp.
Prestolite References
General Motors 695438
Prestolite SAZ4201AC



Forward & Reverse Systems Winches, Golf Carts
15-300
SBD-4301
Your Cost
$107.50
36 Volt DC Special Applications
AMETEK relay formally Prestolite.
"Forward & Reverse Systems
(2 Required) Normally Open & Normally Closed
Circuits Circuitry SPDT
100 Amp NC Copper
150 Amp NO Silver

Mounting Holes 7.0mm Wide x 58.9mm Center to Center
Contacts: Copper/Silver
Housing : plated steel
Voltage Rating 36V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating

John Deere & International Truck Applications SBD4301

Forward & Reverse Systems Winches, Golf Carts
15-301
SBD-4201
Your Cost
$72.50
12 Volt DC Special Applications
AMETEK brand relay formally Prestolite.
"Forward & Reverse
(2 Required) Systems Winches,
Golf Carts"
3 Terminal Grounded Case Circuit
Normally Open & Normally Closed Circuits
Circuitry SPDT
Contacts : Copper
Housing : plated steel
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 100 Amp
SBD4201 Can Use SBD-4202D

Click On Relay
For More information

Click Here For More Information On Ametek Plastic Case Relays
15-307
SBC-4201B

Your Cost
$56.50

AMETEK 12 Volt DC High Current Applications
Power up relay,Electric Cooling Fans,Automotive
Electrical Accessories Applications.
Case Ground.
Has R terminal Feature
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; (2) 10-32 thread
and 2 = 5/16"-18 thread.
Continuous Rating100 Amp.
SBC4201B

Click On Relay
For More Information

Monarch 3335,98240 Prestolite SAS5202B , SAS-5202B

15-312
SAS-5202B

Your Cost
$61.50

AMETEK / PRESTOLITE
12 Volt DC Special Applications
Curved Mounting Base with 5.6mm x 7mm Oval Mounting Holes-49mm Apart.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Copper
Housing : plated steel
Voltage Rating 12V DC
2 Terminal copper; 10-32 thread
and 2 5/16"-24 thread.
Intermittent Duty Rating 100 Amp

Monarch 03335, 3335, 98240
Prestolite SAS5202B, SAS-5202B
Click On Relay
For More information

Monarch / Bucher 3463, SAS-5402B, SAS5402B, 15-314, 15-239
15-314
SAS-5402B
Your Cost
$61.50
AMETEK 24 Volt DC High Current Applications
Power up relay,Pump Motors
Insulated Ground.
Curved Base 0.22 Slot
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 24V DC
Terminals copper; (2) 10-32 thread
2 = 5/16"-18 thread.
Intermittent Duty Rating
SAS-5402B
SAS5402B
Monarch/Bucher 3463
Replaces 15-239 Ametek
Click On Relay
For More information

Click Here For More Information On Ametek Plastic Case Relays SBC-4201C 12 Volt 100 Amp
15-322

SBC-4201C

Your Cost
$64.50
AMETEK 12 Volt DC High Current Applications
Power up relay,Electric Cooling Fans,Automotive Electrical Accessories Applications.
Insulated Ground.
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; (2) 10-32 thread
2 = 5/16"-18 thread.
Continuous Rating100 Amp.
SBC4201C
Click On Relay
For More Information

Forward & Reverse Systems Winches, Golf Carts

15-323
SBD-4201A
Your Cost
$72.50
12 Volt DC Special Applications
AMETEK brand relay formally Prestolite.
"Forward & Reverse Systems like Winches ,Ramsey & Warn Winches Control Box's,Golf Carts
(2 Required)
and much more"
Insulated Ground Circuit
Normally Open & Normally Closed Circuits
Circuitry SPDT
Contacts : Copper
Housing : plated steel
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Rating 100 Amp
SBD4201A
Click On Relay
For More Information

24 Volt Forward & Reverse Systems Winches, Golf Carts

15-326
SBD-4401
Your Cost
$83.75
24 Volt DC Special Applications
AMETEK brand relay formally Prestolite.
"Forward & Reverse Systems like Winches ,Ramsey & Warn Winches Control Box's,Golf Carts (2 Required)
Insulated Ground Circuit
Normally Open & Normally Closed Circuits
Circuitry SPDT
Contacts : Copper
Housing : plated steel
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Rating 100 Amp

Prestolite 15-443, SBD4401
Can Replace White Rodgers
70-911 / 70-317221-5A

Click On Relay
For More information

SAZ-4401, 15-330,  24 Volt DC Intermittent Duty
15-330
SAZ-4401
Your
Cost
$48.50

24 Volts Ametek / Prestolite
4 Terminal
Insulated Ground Circuit
100 Amp Intermittent Duty
90 Degree Mounting Base
SPST Copper Contacts
Plastic With Sealed Case
(2) 5/16-24 Load Terminals
(2) 10-32 Coil Terminals
SAZ-4401, SAZ4401
Click On Relay
For More Information

24 Volt Intermittent Duty Prestolite SAS5402C

15-337
SAS-5402C
Your Cost
$62.50
24 Volts Ametek / Prestolite
4 Terminal
Insulated Ground Circuit
100 Amp Intermittent Duty
Curved Mounting Base
SPST
Copper Contacts
Metal Case
5/16-24 Load Terminals
10-32 Coil Terminals
SAS5402C
Click On Relay
For More information

SAZ-4201AL OMC Marine 581528
15-340
SAZ-4201AL
Your
Cost
$82.50

Prestolite, Ametek Starter Relay
12 Volt DC
H. D. Intermittent Duty
100 Amp Current Rating
4 Terminal
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
2 - 10-32 Threaded Excitation Stud
Flat Mounting Base with 14mm x 7mm
Oval Mounting Holes - 44mm
90 Degrees Apart
Insulated Sealed Case
Stainless Base Plate
References:

OMC 581528
Prestolite SAZ4201AL,

Click On Relay
For More Information

Forward & Reverse Systems Winches, Golf Carts

15-341
SBD-4201E
Your Cost

$76.50

12 Volt DC Special Applications
AMETEK brand relay formally Prestolite.
"Forward & Reverse Systems
Warn & Ramsey type Winches, Golf Carts
(2 Required) "
Grounded Case Circuit
Normally Open & Normally Closed Circuits
Circuitry SPDT
Contacts : Copper
Housing plated steel
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
H. D. Intermittent duty up to 100 Amp SBD4201E ,
May Replace SBD-4201D,SBD4201D
Click On Relay
For More information

SBC-4201A 100 Amp 12 Volt Continuous Duty Relay.
15-342
SBC-4201D
Your Cost
$51.50

Prestolite, Ametek Starter Relay
12 Volt DC
Continuous Duty
100 Amp Current Rating
3 Terminal
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
Contacts : Copper
Flat Mounting Base with
14mm x 7mm
Oval Mounting Holes:
44mm 90 Degrees Apart

References: John Deere AR73144
Replaced Prestolite
15-299, SBC4201A, SBC4201D
Click On Relay
For More information

SBC-4201E 100 Amp 12 Volt Continuous Duty Relay.
15-345
SBC-4201E
Your Cost
$49.50
Prestolite, Ametek Starter Relay
12 Volt DC
Continuous Duty
100 Amp Current Rating
3 Terminal Insulated coil
Contacts : Copper
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
Flat Mounting Base with
Flat Mounting Base with 7mm Mounting Holes-66.7mm & 180 Degrees Apart,
References: Komatsu 107655C1
Prestolite SBC4201E

Click On Relay
For More information

12 Volt 100 Amp Intermittet Duty SAZ-4201BC
15-368
SAZ-4201BC
Your Cost
$50.50

Prestolite, Ametek Relay
12 Volt 100 Amp Intermittent Duty
Flat 180 (F180)
SPST, Normally Open Contacts
(2) 5/16-18
(2) 10-32 Threaded Terminals
Plastic Case
8V Pickup
3.1 Coil Ohms
Potted Coil Leads
Sealed Case
SAZ4201BC
Click On Relay
For More information

SBC-4201F 100 Amp 12 Volt Continuous Duty Relay.
15-379
SBC-4201F
Your Cost
$62.75

Prestolite, Ametek Relay
12 Volt DC
Continuous Duty
100 Amp Current Rating
4 Terminal Insulated coil
Contacts : Copper
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
2 - 10-32 Threaded Excitation Stud
Flat Mounting Base with
14mm x 7mm
Oval Mounting Holes:
44mm 90 Degrees Apart

References: John Deere
Replaced Prestolite
SBC420F, SBC4201F


Click On Relay
For More Information

24 V SPDT 200 Amp Normally Open Circuit & 150 Amp Normally Closed Circuit SBD5401 15-381

15-381
SBD-5401
Your Cost
$124.50

24 Volt DC Heavy Duty Special Applications
AMETEK brand relay formally Prestolite.
"Forward & Reverse Systems like Winches , Control Box's, Golf Carts and much more
(2 Required) "
Insulated Ground Circuit
Normally Open Circuit 200 Amp
Normally Closed Circuit 150 Amp
Circuitry SPDT
Contacts : Silver
Housing : plated steel
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating.
SBD5401

Click On Relay
For More Information

6 Volt SPDT Relay Contionuous Duty 100 Amp NC Circuit 150 NO Circuit

15-382
SBD-4601
6 Volt
Your Cost
$112.50

6 Volt DC Heavy Duty Special Applications
AMETEK brand relay formally Prestolite.
Insulated Ground Circuit
"Forward & Reverse Systems like Winches , Control Box's,
(2 Required)

Normally Open Circuit 150 Amp
Normally Closed Circuit 100 Amp
Circuitry SPDT
Contacts : Copper / Silver
Housing : plated steel
Voltage Rating 6 V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating.
SBD4601
Johnson Electric
5118740, SO51187

Click On Relay
For More Information

Forward & Reverse Systems Winches, Golf Carts NO-200 Amp- NC-150 Amp

15-386
SBD-4201G
Your Cost
$135.50

12 Volt DC Heavy Duty Special Applications
AMETEK brand relay formally Prestolite.
"Forward & Reverse Systems like Winches ,Ramsey & Warn Winches Control Box's,Golf Carts
(2 Required)
and much more"
Insulated Ground Circuit
Normally Open Circuit 200 Amp
Normally Closed Circuit 150 Amp
Circuitry SPDT
Contacts : Silver
Housing : plated steel
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating.
SBD4201G
May Replace Stancor / White Rogers
70-910 / 70-311221-5A

SAZ-4201N 12 VOLT 100 AMP INTERMITTENT DUTY RELAY
15-3F
SAZ-4201N
Your Cost
$36.50

Prestolite, Ametek Starter Relay
12 Volt DC
Intermittent Duty
100 Amp Current Rating
4 Terminal
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
1 - 10-32 Threaded Relay Terminal
Flat Mounting Base Oval Mounting Holes 90 Degrees Apart
With Relay Terminal
Grounded Case
References: SAZ4201N
SAZ-4201N, MOTORCRAFT SW3,

D20Z11450A, SW1507, SW1507A
Click On Relay
For More Information

15-407 SAE-J1171 Starter RElay 12 Volt Intermittent Duty Relay.
15-407
SAS-4211Y
Your
Cost
$58.50
Prestolite, Ametek Starter Relay
12 Volt DC
Intermittent Duty
SAE-J1171 Marine Rated
4 Terminal
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
1 - 10-32 Threaded Relay Terminal
Prestolite 15-174, 15-370, SAS4211Y, SAS5211Y, SAS-5211Y
Volvo 8348941
Used on MDY-7054
MDY-6139, MDY-6139S
Marine Series Prestolite Starters

Use Cole Hersee 24103
Click On Relay
For More information

Ametek Relay 12 Volts DC Heavy Duty Intermittent
15-408
SAZ-4201BJ
Your Cost
$39.50

Ametek Relay
12 Volts DC
Number of Terminals: 3

Heavy Duty Intermittent
5/16-18 Threaded Motor & Battery Studs
10-32 Threaded Excitation Terminal
Curved Mounting Base
7mm x 14mm Mounting Slots-39mm Apart
100 Amp Current Rating
Application: AMETEK/Prestolite
AMETEK / Prestolite 15-282, 15-522 SAZ4201BJ, SAZ4201BJ2

Click Here For More Information

24 Volt Intermittent Duty Relay.
15-416
SAW-5406
Your
Cost
$61.50

AMETEK 24 Volt DC
Intermittent Duty 4 Terminal
Flat Mounting Base.
Mounting Base with 10mm x 7mm Oval Mounting Holes-42.5mm Apart
UL Recognized
100 Amp Current Rating
Insulated Case
Fenner Stone E3-1010-00
Prestolite SAW5406
May Replace Cole Hersee 24008

Click On Relay
For More information

Click Here For More Information On Ametek Plastic Case Relays
15-418
SAZ-4201BR

Your Cost
$36.75

AMETEK 12 Volt DC
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; (2) 10-32 thread
and 5/16"-18 thread.
Intermittent Duty Rating 100 Amp.
Sealed Case
Prestolite References
15-274, 15-360, 15-391,
15-441, SAZ4201AW, SAZ4201BR, SAZ4201CJ, SAZ4201R

Click Here For More Information

24 Volt Continuous Duty Relay
15-419
SAS-4414
Your
Cost
$64.80


AMETEK 24 Volt DC
Continuous Duty
3 Terminal
Flat Mounting Base.
7mm x 12mm Mounting Slots 47mm Apart,
100 Amp Current Rating
Grounded Case
Replaces John Deere AT69528
Prestolite 15-181,
SAS4414, SAS-4414
Can Replace Cole Hersee 24124
White Rodgers 70-915



Click On Relay
For More information

SAZ-4401W 24 Volt DC Intermittent Duty
15-422
SAZ-4401W
Your
Cost
$115.50

Prestolite, Ametek Starter Relay
24 Volt DC,HD Intermittent Duty
100 Amp Current Rating
4 Terminal
Contacts : Copper
Sealed Case

1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
1 - 10-32 Threaded Relay Terminal
Flat Mounting Base with
14mm x 7mm
Oval Mounting Holes - 44mm
90 Degrees Apart

John Deere AT71088
Prestolite 15-357, SAZ4401W

Click On Relay
For More information

Click Here For More Information On Ametek Plastic Case Relays

15-433
SBC-4401B

Your Cost
$59.75


AMETEK 24 Volt DC
High Current Applications.
Power up relay,Electric Cooling Fans,Golf Carts,
24 volt Electrical Accessories Applications.
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 24V DC
Terminals copper; (2) 10-32 thread
and 5/16"-18 thread.
Continuous Rating 100 Amp.
SBC4401B
Click On Relay
For More information

Prestolite, Ametek Starter Relay 12 Volt DC 100 Amp Current Rating.
15-436

SAZ-4201CG
Your Cost
$41.50


Prestolite, Ametek Starter Relay

12 Volt DC
Intermittent Duty
100 Amp Current Rating
4 Terminal
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
1 - 10-32 Threaded Relay Terminal
Flat Mounting Base with 14mm x 7mm
Oval Mounting Holes - 44mm
90 Degrees Apart
Suppression Diode on Coil
With Relay Terminal
Grounded Case
References:
Motorcraft SW1533, SW1533A
Prestolite SAZ4201CG


Click On Relay
For More information

SAZ-4201EA Prestolite, Ametek Starter Relay 12 Volt DC 100 Amp Current Rating.
15-450

SAZ-4201EA
Your Cost
$42.75
Prestolite, Ametek Starter Relay
12 Volt DC
Intermittent Duty
100 Amp Current Rating
3 Terminal
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
Flat Mounting Base with 14mm x 7mm
Oval Mounting Holes - 44mm
90 Degrees Apart
Suppression Diode on Coil
Grounded Case
Stainless Base Plate
References:
Motorcraft SW1951B,SW1951C
Prestolite SAZ4201EA
Click On Relay
For More information

Prestolite SAZ-4201DUY Yamaha 10122400 12 Volt 200 Amp,  600 Amp Surge Rating.
15-451

SAZ-4201DUY
Yamaha 10122400
Your Cost
$113.50


P
restolite, Ametek
12 Volts
4 Terminal
Intermittent Duty
Insulated Base
Stainless Steel Plunger Pin
Stainless Base Plate
Circle Potted Coil
Marinized to SAE-J1171
Vibration Resistant Design
Yamaha OEM Version
100 Amp, 600 Amp Cranking Surge Rating.
Prestolite SAZ4201DUY
Yamaha 10122400


Click On Relay
For More information

Replaces: Mercury Marine 460917, 89F460917-1 Prestolite 15-295,SAZ4201AB, SAZ4201ABY
15-457
SAZ-4201ABY
Your Cost
$82.50

12 Volt AMETEK / Prestolite
Number of Terminals 4
Intermittent Duty
Insulated Ground Circuit
(2) 5/16-18 Threaded Motor & Battery Studs,
(2) 10-32 Threaded Excitation & Ground Terminals,
100 Amp
Flat Mounting Base
180 Degrees Apart
Vibration Resistant Design
Stainless Steel Plunger Pin
Stainless Base Plate
Circle Potted Coil
Marinized to SAE-J1171
Certified
Replaces:
Mercury Marine 460917, 89F460917-1
Replaces Prestolite:
15-295, SAZ4201AB, SAZ4201ABY

SAZ-4201AB, SAZ-4201ABY


Click On Relay
For More information

15-466 / SBC-4401D 24 Volt Special Application.
15-466
SBC-4401D
Your Cost
$181.50

Prestolite, Ametek 24 Volts
100 Amp Continuous Duty
4 Terminal Insulated Base
No Bracket
Special Assembly
References: Prestolite 15-466 SBC4401D

Click On Relay
For More information

15-468 / SAZ-4401AC General Motors Applications
15-468
SAZ-4401AC
Your Cost
$107.50
Prestolite, Ametek
24 Volts
100 Amp Intermittent Duty
4 Terminal Insulated Base
Application:
General Motors Applications

References:
Prestolite 15-524, 15-525, SAZ4401AC
SAZ-4401AC1 SAZ-4401AC2

MUF-6301 Ametek
Prestolite Pump Motor

Click On Relay
For More information

15-470 Prestolite 24 Volt 100 Amp Continuous Duty Relay, SBC-4401C
15-470
SBC-4401C
Your Cost
$165.50


AMETEK 24 Volt DC

High Current Applications.
Power up relay,Electric Cooling Fans,Starter Relay,24 volt Electrical Accessories Applications.
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 24V DC
Terminals copper; (2) 10-32 thread
and 5/16"-18 thread.
Continuous Rating 100 Amp.
SBC4401C

References:
Komatsu 1207387H2
Prestolite SBC4401C, SBC-4401C

Click Here For More Information
6 Volt 100 Amp Continuous Duty Relay
15-476
SAS- 4609
Your Cost
$53.50


Prestolite, Ametek
6 Volts
3 Terminal
Grounded Case
(2) 5/16-18 Motor & Battery Studs
(1)10-32 Threaded Excitation Terminal
Flat Mounting Base
Continuous Duty
100 Amp Current Rating
Cole Hersee 24105
Prestolite SAS4609, SAS-4609


Click On Relay
For More information

15-480 Ametek / Prestolite 24 Volt 100 Amp Continuous Duty Relay, SBC-4401E
15-480
SBC-4401E
Your Cost
$183.50

AMETEK 24 Volt DC
High Current Applications.
Power up relay,Starter Relay,24 volt Electrical Accessories Applications.
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 24V DC
Terminals copper; (2) 10-32 thread
and 5/16"-18 thread.
Flat 180 (F180) Flat Base
Continuous Rating 100 Amp.
Sealed Case
SBC4401E
, SBC-4401E
Osh Kosh Truck Applications
Military Truck Applications


Click Here For More Information

24 Volt Intermittent Duty Prestolite SAS5402D

15-482
SAS-5402D
Your Cost
$133.50


24 Volts Ametek / Prestolite
4 Terminal
Insulated Ground Circuit
100 Amp HD Intermittent Duty
Curved Mounting Base
SPST
Copper Contacts
Metal Case
5/16-24 Load Terminals
10-32 Coil Terminals
SAS5402D, SAS-5402D
Prestolite SAS5402D


Click On Relay
For More information

Ametek / Prestolite Relay 12 Volt  SAZ4201ER, SAZ4201ER1, SAZ4201ER2
15-483
SAZ-4201ER
Your Cost
$66.50

12 Volt AMETEK / Prestolite
Number of Terminals 4
Intermittent Duty
Insulated Ground Circuit
(2) 5/16-18 Threaded Motor & Battery Studs,
(2) 10-32 Threaded Excitation & Ground Terminals,
100 Amp
Mounting Slots
7mm Wide x 53mm Center to Center
Sealed Case
Replaces: Prestolite SAZ4201ER, SAZ4201ER1, SAZ4201ER2

Click On Relay
For More information

SAZ-4201EW Prestolite, Ametek Starter Relay 12 Volt DC 100 Amp Current Rating.
15-486

SAZ-4201EW
Your Cost
$53.50

AMETEK 12 Volt DC
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; (2) 10-32 thread
and (2) 5/16"-18 thread.
Intermittent Duty Rating
100 Amp
600 Amp Inrush .
Flat Mounting Base
Oval Mounting Holes
90 Degrees Apart

Sealed Case
Prestolite References
SAZ4201EW

SAZ-4201EW

Click On Relay
For More information

SAZ-4201EY 12 Volt Intermittent Duty RElay
15-487
SAZ-4201EY
Your Cost
$110.50


Ametek / Prestolite Relay
12 Volts DC
Terminals: 4
H. D. Intermittent Duty
2-5/16-18 Motor & Battery Studs
2-10-32 Threaded Excitation & Ground Terminals, Flat Mounting Base with 7mm Mounting Holes-60mm & 180 Degrees Apart, 100 Amp Current Rating
References:
Prestolite 15-523, SAZ4201EY SAZ4201EY1, SAZ4201GL

SAZ-4201EY, SAZ-4201EY1
SAZ-4201GL


Click On Relay
For More Information

24 Volt 200 Amp Continuous Duty

15-489
SAS-4420

Your Cost
$85.50

AMETEK 24 Volt DC Universal Applications
Power Up Relays,Pump Motors ,High Current Utility Vehicles, Winches, Lift Trucks,
Snow Plows etc.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Silver
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Rating 200 Amp

SAS4420

Click On Relay
For More Information

15-500 / SAS-5402E  AMETEK/Prestolite Motors  Relay 100 Amp Current Rating

15-500
SAS-5402E
Your Cost
$73.50


24 Volts Ametek / Prestolite
4 Terminal
Insulated Ground Circuit
100 Amp Intermittent Duty
Curved Mounting Base 2.22
SPST
Copper Contacts
Metal Case
5/16-24 Load Terminals
10-32 Coil Terminals
UL RECOGNIZED
SPLASH RESISTANT
SAS5402E SAS-5402E
Prestolite SAS5402E

Click On Relay
For More Information

15-307  AMETEK/Prestolite Motors  Relay 100 Amp Continuous duty Current Rating With Diode

15-507
SBC-4201W
Your Cost
$57.50

12 volts Ametek / Prestolite
4 Terminals
Continuous Duty
SPST, 100 Amp, With Diode
Copper Contact
(2) 5/16-18 Threaded Terminals
(2) 10-32 Threaded
Flat 180° Mounting Base
SBC4201W



Click Here For More Information
 AMETEK/Prestolite Motors  Relay 100 Amp Current Rating, SAW4227

15-497
SAW-4227
Your Cost
$55.50

12 volts Ametek / Prestolite
3 Terminals
Continuous Duty
SPST, 100 Amp
(2) 5/16-18 Threaded Terminals
(1) 10-32 Threaded
Mounting Flanges 7.1mm Wide
50mm Center to Center
Ultron Tailgate & Fenner Stone 2145AA
SAW4227

Click On Relay
For More information

15-518 / SAZ-4202A 50 Amp Continuous Duty.
15-518
SAZ-4202A
Your Cost
$47.50

Prestolite, Ametek
12 Volt DC
4 Terminal
50 Amp
Continuous Duty

Insulated Coil
Sealed Case
(2) 5/16-18 Load Terminals
(2) 10-32 Switch Terminal
References:
Prestolite SAZ4202A


Click On Relay
For More information

15-521 / SBC-4201AC 100 Amp Intermittent Duty
15-521
SBC-4201AC
Your Cost
$49.75

Prestolite, Ametek
12 Volt DC
3 Terminal
100 Amp
Continuous Duty

Copper Contact
Grounded Case
Potted Coil Leads
(2) 5/16-18 Load Terminals
(1) 10-32 Switch Terminal
References:
Prestolite SBC4201AC, SBC4201AC2


Click On Relay
For More information

 AMETEK/Prestolite Motors  100 Amp Current Rating,
15-526
SBC-4201AD
Your Cost
$68.75



Prestolite , Ametek Relay
12 Volt
4 Terminal Insulated Ground
(2) 5/16-18 Threaded Terminals.
(2) 10-32 Threaded Terminals.
Continuous Duty
100A Carry Load
Mounting Holes 11.8mm x 7.4mm
Oval x 59.7mm Center to Center
References: Prestolite
SBC4201AD , SBC-4201AD, SBC 4201AD
Can Use White Rodgers 124-902



Click On Relay
For More information

 AMETEK/Prestolite Motors  100 Amp Current Rating,
15-527
SAZ-4201FP
Your Cost
$36.75



Ametek Relay
12 Volts DC
Number of Terminals: 3
Intermittent Duty
(2) 5/16-18 Threaded Battery & Motor Terminal
10-32 Threaded Excitation Terminal
Curved Mounting Base with Slotted Mounting Holes
100 Amp Current Rating
39.25mm & 180 Degrees Apart
Application: AMETEK/Prestolite Motors
Prestolite SAZ4201FP, SAZ4201FP1, SAZ4201FP2
Click On Relay
For More information

 AMETEK/Prestolite Motors  100 Amp Current Rating,
15-544
SAZ-4201FY
Your Cost
$63.50
Ametek Relay
12 Volts DC
Number of Terminals: 3
Heavy Duty Intermittent
5/16-18 Threaded Motor & Battery Studs
10-32 Threaded Excitation Terminal
Curved Mounting Base
7mm x 14mm Mounting Slots-39mm Apart
100 Amp Current Rating
Application: AMETEK/Prestolite Motors
Fire Truck Water Pump Primer Motors
Reference Numbers:
Prestolite SAZ4201FY, SAZ4201FY1, SAZ4201FY2
Click On Relay
For More information

12 Volt 200 Amp Relay Solenoid
15-550
SBJ-4201
Your Cost
$124.50

Prestolite/ Ametek
12 Volt 200 Amp Relay Solenoid
Continuous Duty Silver Contacts.
4 Terminal Insulated Ground
(2) 5/16-18 Threaded Terminals.
(2) 10-32 Threaded Terminals.
SBJ-4202 , SBJ4201
Click On Relay
For More information

15-551 / SBJ-4401 24 Volt 200 Amp Relay Solenoid
15-551
SBJ-4401
Your Cost
$129.50

Prestolite/ Ametek
24 Volt 200 Amp Relay Solenoid
Continuous Duty Silver Contacts.
4 Terminal Insulated Ground
(2) 5/16-18 Threaded Terminals.
(2) 10-32 Threaded Terminals.
SBJ-4401 , SBJ4401
Spartan Motors Home
Fire Apparatus #13617
Click On Relay
For More information

Ametek Relay SAZ4201GE
15-588
SAZ-4201GE
Your Cost
$66.50
Prestolite / Ametek Relay
12 volts,
4 Terminals
With R-Terminal
Intermittent Duty
100 Amp
Heavy Duty Plastic Case
Application: John Deere
Prestolite SAZ4201GE



12 volt 100 Amp Intermittent Duty
SAW-5229
Your Cost
$51.50

12 Volts Ametek / Prestolite
4 Terminal
Insulated Ground Circuit
100 Amp Intermittent Duty
Base Curved 2.22in Radius (C222)
SPST
Copper Contacts
UL Recognized
Metal Case
5/16-24 Load Terminals
10-32 Coil Terminals
SAW5229
15-510
Fenner Stone 1866CA


Click On Relay
For More information

SAZ-4201GF 12 Volt 100 Amp Intermittent Duty
S
AZ-4201GF
Your Cost
$35.50



AMETEK/ PRESTOLITE
12 Volts DC
Number of Terminals: 3
Grounded Case
Intermittent Duty
5/16-18 Threaded Motor & Battery Studs
10-32 Threaded Excitation Terminal
Curved Mounting Base
100 Amp Current Rating
Application: AMETEK/Prestolite Motors

MTE Hydraulic Pump
Flanges 7.1mm Wide
50mm Center to Center
SAZ4201GF

Click On Relay
For More information

12 Volt AMETEK/ PRESTOLITE,Replaces  Monarch 07522 Hydraulic Pump Motors.
S
AZ-4201GJ
Your Cost
$35.50

12 Volt ,AMETEK/ PRESTOLITE,
Monarch
Intermittent Duty
Application: Monarch Pump Motor Relay
Monarch Hydraulic Pump Motors
References: Monarch 07522, 7522

SAZ4201GJ

Click On Relay
For More information

24 Volt AMETEK/ PRESTOLITE Relay
SAZ-4401AM

Your Cost
$39.50



AMETEK/ PRESTOLITE

24 Volts DC
Number of Terminals: 4
Heavy Duty Intermittent Duty
(2) 5/16-18 Threaded Studs
(2) 10-32 Threaded Excitation Studs
Curved Mounting Base
100 Amp Current Rating
600A Maximum Inrush
SAZ4401AM

Click On Relay
For More information

12 Volt AMETEK/ PRESTOLITE Relay
SBC-4201AG

Your Cost
$51.50


AMETEK/ PRESTOLITE

12 Volts DC
Number of Terminals: 3
Grounded Case
Continuous Duty
5/16-18 Threaded Motor & Battery Studs
10-32 Threaded Excitation Terminal
Curved Mounting Base
100 Amp Current Rating
600A Maximum Inrush
SBC4201AG
May Replace
Trombetta 634-1211-012
Click On Relay
For More information

SBC-4201AK 100 Amp 12 Volt Continuous Duty Relay With Diode.
SBC-4201AK
Your Cost
$51.50

Prestolite, Ametek Starter Relay
12 Volt DC
Continuous Duty
100 Amp Current Rating
3 Terminal With
Suppression Diode
1 - 5/16-18 Threaded Motor Stud
1 - 5/16-18 Battery Stud
1 - 10-32 Threaded Excitation Stud
Contacts : Copper
9.8 Ohm Coil Resistance
Flat Mounting Base with
14mm x 7mm
Oval Mounting Holes:
44mm 90 Degrees Apart

Replaced Prestolite SBC4201AK
Ford F4HT12B536AA, F4HZ12B536AA

200 Amp 12 Volt Continuous Duty Relay
SBC-4201AP
Your Cost
$48.50

Prestolite, Ametek
12 Volt
200 Amp
Continuous Duty
2 = 5/16 - 18 Studs
2 = 10-32 Terminals
Copper-Cadmium Contact
Insulated Case Application:
Curved 2.22in Radius (C222)
Monarch & MTE Hydraulic Pumps

SBC4201AP


Click On Relay
For More information

Click Here For More Information On Ametek Plastic Case Relays

SBC-4201L

Your Cost
$48.50
AMETEK 12 Volt 100 Amp DC
High Current Applications.
Power up relay,Electric Golf Carts,
12 Applications.
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Copper
Voltage Rating 12 VCD
Terminals copper; (2) 10-32 thread
and (2) 5/16"-18 thread.
Intermitted Duty Rating 100 Amp.
SBC4201L, 1013609 Club Car
Click On Relay
For More information

12 Volt 200 Amp Continuous Duty Silver Contact With Diode
SBJ-4201A
Your Cost
$121.50

Prestolite/ Ametek
12 Volt 200 Amp Relay Solenoid
Continuous Duty Silver Contacts.
4 Terminal Insulated Ground
With Diode on Coil
(2) 5/16-18 Threaded Terminals.
(2) 10-32 Threaded Terminals.
SBJ-4201A , SBJ4201
A
May Replace Pollak Relay Number 52-337

SBJ-4203 Continuous Duty 200 AMP SILVER CONTACT
SBJ-4203
Your Cost
$84.50

Click On Relay
For More information


Prestolite, Ametek
12 Volt
200 Amp Silver Contact
Continuous Duty
4 Terminal
2 = 5/16 - 18 Studs
2 = 10-32 Terminals
Insulated Case
Flat 180 Degree Base
SBJ4203

Click On Relay
For More information

12 Volt 200 Amp Continuous Duty Silver Contact
SBJ-4207
Your Cost
$78.50
Prestolite, Ametek
12 Volt
200 Amp Silver Contact
Continuous Duty
4 Terminal
2 = 5/16 - 18 Studs
2 = 10-32 Terminals
Insulated Case
SBJ4207

Click On Relay
For More information

SBJ-5255-1, 200 Amp 12 Volt Continuous Duty Silver Contact.
SBJ-5255-1
Your Cost
$49.50



Prestolite, Ametek 12 Volt
200 Amp
Continuous Duty
Silver Contact
2 = 5/16 - 18 Studs
2 = 10-32 Terminals
Insulated Case Application:
Hydraulic Pumps Motors
Curved 2.22in Radius (C222)
Replaces SBJ5255, SBJ-5255, SBJ52551, UL Certified

Click On Relay
For More information

200 Amp 12 Volt Continuous Duty Monarch & MTE Hydraulic Pumps, Monarch 11000
SBJ-6255
Your Cost
$96.90


Prestolite, Ametek
12 Volt
200 Amp
Continuous Duty
Monarch OEM Version

2 = 5/16 - 18 Studs
2 = 10-32 Terminals
Insulated Case Application:
Monarch & MTE Hydraulic Pumps
Curved 2.22in Radius (C222)
Monarch 11000
SBJ6255

May be used to replace SBC4201AP
SBC-4201AP


SBD-4202D 12 VOLT 3 TERMINAL SPDT CONTINUOUS DUTY 100/100 AMP
SBD-4202D
Your Cost
$66.50

12 Volt DC Special Applications
AMETEK brand relay formally Prestolite.
"Forward & Reverse
(2 Required) Systems Winches,
Golf Carts"
3 Terminal Grounded Case Circuit
Normally Open & Normally Closed Circuits
Circuitry SPDT
Contacts : Copper
Housing : plated steel
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 100 AmP
SBD4202D / SBD-4202D

Can Use 15-301 / SBD4201

Back To Top Of Page
Bosch
Relays Continuous Duty & Intermittent Duty Relays 12 Volt and 24 Volt


Click On Image For
More Details



Click On Relay For More Detalis - Bosch Heavy Duty 75 Amp  Relay 0 332 002 150
0 332 002 150
Superseded By
0 332 002 168
C/U Use TYCO
1904000-1


75 Amp 12 VOLT DC Power Bosch Relay.
Bosch Relay 0 332 002 150
Continuous Duty
This 4 Prong Heavy Duty Relay has many
Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With
(2) Activating Terminals & Housing.

Bosch 0332002150
0-332-002-150

Can Replace Lucas 33RA,
SRB600 Black, SRB630, Blue SRB631, Green, Series Relays
I/D Intermittent Duty 12 Volt 60 Amp Tyco V23232 D0001 X001
V23232D0001X001
V23232-D0001-X001
1904000-1


Click On Image For
More Details

Click On Relay For More Detalis - Bosch Heavy Duty 75 Amp  Relay 0 332 002 155
0 332 002 155
Superseded By
0 332 002 168|
C/U Use TYCO
1904000-1


75 Amp 12 VOLT DC Power Bosch Relay.
0 332 002 155
12 Volt Continuous Duty
This 4 Prong Heavy Duty Relay has many Automotive & Motorcycle uses,
it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With
(2) Activating Terminals & Housing.

Bosch 0332002105, 0332002155
0-332-002-105 , 0-332-002-155,
V23232A0001X002
V23232A0001Y002


Click On Image For
More Details

Click On Relay For More Detalis - Bosch Heavy Duty 75 Amp  Relay 0 332 002 156
0 332 002 156
Your Cost
$54.50

75 Amp 12 VOLT DC Power Bosch Relay.
0 332 002 156
Continuous Duty
This 4 Prong Heavy Duty Relay has many
Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With
(2) Activating Terminals & Housing.

Features:Parallel & Series Diodes
0332002156 Bosch Relay
Tyco V23232 A0001 X003
V23232A0001X003
V23232-A001-X003
V23232A001X003-EV-260
V23232-A001-X003-EV-260
TYCO 1904001-2
1N5408 3 Amp 1200 Volt Diode

Click On Image For
More Details


Click On Relay For More Detalis - Bosch Heavy Duty 75 Amp  Relay 0 332 002 168
0 332 002 168
V23232-A0001-Y015
Your Cost
$64.50

75 Amp 12 VOLT DC Power Bosch Relay.
Bosch Relay 0 332 002 168
Continuous Duty W/Resistor
This 4 Prong Heavy Duty Relay has many
Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With
(2) Activating Terminals & Housing.

Can Replace Lucas 33RA,
SRB600 Black, SRB630, Blue SRB631, Green, Series Relays
0332002150, 0 332 002 155 Bosch
0332002168
V23232A0001Y015
H/D Duty 12 Volt 75 Amp Tyco V23232 D0001 X001
V23232D0001X001
V23232-D0001-X001
1904000-1


Click On Image For
More Details


24 Volt 50 Amp Bosch Relay 0 332 002 250
Old # 0 332 002 250
USE 0 332 002 258
Can Use Tyco 1904002-2


50
Amp 24 VOLT DC Power Bosch Relay.
Bosch Relay 0 332 002 250
Continuous Duty
This 4 Prong Heavy Duty Relay has many
Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With (2) Activating Terminals & Housing.
Can Replace Lucas
33RA SRB601 Red, 33RA SRB632 Blue Relay
0332002250 Bosch 24 Volt Relay
C/D Continuous Duty.
0332002258 0-332-002-258

Tyco V23232 E0002 X007
V23232E0002X007, V23232-E0002-X007


Click On Image For
More Details


24 Volt 50 Amp Bosch Relay 0 332 002 255


Old # 0 332 002 255
0 332 002 258
Can Use Tyco 1904002-2

Bosch Relay
50 Amp 24 VOLT DC.
Bosch Relay 0 332 002 255
Continuous Duty
4 Prong Heavy Duty Relay
Has many Automotive uses
NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With (2) Activating Terminals & Housing.

Replaces 0332002201
0 332 002 201, 0-332-002-201
0332002255 Bosch Relay 24 Volt

Tyco V23232A0002X008, V23232A0002Y008


Click On Image For
More Details


24 Volt 50 Amp Bosch Relay 0 332 002 256


0 332 002 256
Your Cost
$58.50

Bosch Relay
50 Amp 24 VOLT DC.
Bosch Relay 0 332 002 256
Continuous Duty
4 Prong Heavy Duty Relay
Has many Automotive uses
NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With (2) Activating Terminals & Housing.

Features:
Parallel & Series Diodes

Replaces 0 332 002 256 315
0332002256 Bosch Relay 24 Volt

Tyco V23232 A0002 X009
V23232A0002X009
V-23232-A0002-X009
V23232-A0002-X009

V23232A0002X009-EV-260
1904001-5
19040015

23232-A0002-X009
V23232-A0002-Y009
V23232A0002Y009


Click On Image For
More Details


24 Volt 50 Amp Bosch Relay 0 332 002 250
0 332 002 258
Your Cost
$59.50
Can Use Tyco 1904002-2


50
Amp 24 VOLT DC Power Bosch Relay.
Bosch Relay 0 332 002 250
Continuous Duty
This 4 Prong Heavy Duty Relay has many
Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With (2) Activating Terminals & Housing.
Can Replace Lucas
33RA SRB601 Red, 33RA SRB632 Blue Relay
0332002250 Bosch 24 Volt Relay
C/D Continuous Duty.
0332002258 0-332-002-258

Tyco V23232 E0002 X007
V23232E0002X007, V23232-E0002-X007

Click Here For More Information
Bosch Relay 0 332 015 001
0 332 015 001
0 332 015 001 7ZO
Your Cost
$27.50

Bosch Relay
DPST Dual Make NO Contact
15
Amp 12 VOLT DC Power Relay.
0332015001, 03320150017ZO
5 Prong Bosch Relay
Continuous Duty
Dual #87b & 87Contact
Power Two Isolated Circuits.
Ap
plication:Automotive & Industrial.
Relay Housing BRHKB With (5) Terminals.
Complete Kit 0332015001K

Bosch Housing 3 334 485 007

Bosch Housing Number 3334485007
Please Specify if you
need 12-10 ga Terminals.

Click Here For More Information
Click Here For More Information

0 332 015 006
Your Cost
$29.50

Bosch Relay
DPST Dual Make NO Contact
15
Amp 12 VOLT DC Power Relay.
0332015006 5 Prong Bosch Relay
Continuous Duty
Dual #87b & 87Contact
Power Two Isolated Circuits.
Ap
plication:Automotive & Industrial.
Relay Housing BRHKB With (5) Terminals.
Please Specify if you
need 12-10 ga Terminals.

Complete Kit 0332015006K

Bosch Housing 3 334 485 007

Bosch Housing Number 3334485007

Click Here For More Information
Click Here For More Information
0 332 015 008
Your Cost
$29.50
Bosch Relay
DPST Dual Make NO Contact
10
Amp 24 VOLT DC Power Relay.
0332015008 5 Prong Bosch Relay
Continuous Duty
Dual #87b & 87Contact
Power Two Isolated Circuits.
Application:Automotive & Industrial.

Relay Housing BRHKB With (5) Terminals.
Please Specify if you
need 12-10 ga Terminals.

Complete Kit 0332015008K
V23134-M66-Y916 ,V23134M66Y916

Bosch Housing 3 334 485 007

Bosch Housing Number 3334485007

Click Here For More Information
Click Here For More Information
0 332 017 300
Your Cost
$9.75

Bosch Relay
SPST NO Contact
12V DC Coil
20 Amp

Continuous Duty
2 = 3/16" (4.8mm) Coil Terminals
2 = 1/4" (6.3mm) Load Terminals
0 332 011 007, 0332017300
0 332 017 303 0332011007 0332017300 0332017303
Tyco Number V23274A1601X001, V23274A1601Y001
Hella Number 007813011 4RA007813-01
, 4RD931524-02
965453041, H41524021,

0 332 019 103 Bosch 50 Amp 12 VOLT DC Power Relay.
0 332 019 103
Your Cost
$10.75

50 Amp 12 VOLT DC Power Relay.
Features a NO circuit

No Mounting Bracket
Continuous Duty With Resistor
This 4 Prong Bosch Relay has many uses.
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

Complete Kit 0332019103K
Can accommodate 10ga wire size.
Please Specify if you
need 12-10 ga Terminals.
Bosch Relay 0 332 019 103 12 Volt

0 332 019 110 Bosch 50 Amp 12 VOLT DC Power Relay.
0 332 019 110
Your Cost
$10.75
50 Amp 12 VOLT DC Power Relay.
Features a NO circuit.
Continuous Duty With Resistor
This 4 Prong Bosch Relay has many uses.
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

Complete Kit 0332019110K
Can accommodate 10ga wire size.
Please Specify if you
need 12-10 ga Terminals.
Bosch Relay 0 332 019 110 12 Volt
0332019110 Bosch 4 Pin Relay
Bosch Housing 3 334 485 007

Bosch Housing Number 3334485007
May replace 0 332 209 138 Relay if only 4 terminals are needed


Click Here For More Information
Bosch 12 Volt Relay Continuous Duty - Dual Contact 0 332 019 150 .
0 332 019 150
Your Cost
$16.75
Bosch Relay
DPST Dual NO Contact
30
Amp 12 VOLT DC Power Relay.
5 Prong Bosch Relay
Continuous Duty - Dual #87 Contact
Relay Housing BRHK With (5) Terminals.
Please Specify if you
need 12-10 ga Terminals.

Complete Kit 0 332 019 150K

Replaces,
0332019150, 0-332-019-150
0 332 014 150,0332015150,
0332003011
0 332 003 011
Bosch Housing 3 334 485 007

Bosch Housing Number 3334485007
Can Replace Hella 933791061


Click Here For More Information
Bosch 12 Volt Relay Continuous Duty - Dual Contact 0 332 019 151 .
0 332 019 151
Superseded By:
0986AH0251
Your Cost
$17.50

Bosch Relay
DPST Dual NO Contact

30 Amp 12 VOLT DC Bosch Relay.
0332019151 5 Prong Bosch Relay
Features a Dual NO circuit.
Continuous Duty-Dual #87 Contact
Applications: Industrial applications.
Relay Housing BRHK With (5) Terminals.

Please Specify if you
need 12-10 ga Terminals.

Complete Kit
0986AH0251K
0 332 019 151
Bosch Housing 3 334 485 008
Bosch Housing Number 3334485008

Click On Image For
More Details

Bosch 24 Volt Relay Continuous Duty - Dual Contact.
0 332 019 203
Your Cost
$18.75

Bosch Relay
DPST Dual NO Contact

2
0 Amp 24 VOLT DC Bosch Relay.
Bosch 0332019203 5 Prong Relay.
Features a NO circuit.
Continuous Duty - Dual #87Contact
Applications: many Industrial applications.
Relay Housing BRHK With (5) Terminals.
Please Specify if you need
12-10 ga Terminals
.
Complete Kit 0 332 019 203K
Bosch Relay 0 332 019 203 24 Volt

Bosch Housing 3 334 485 007
Replaces 0 332 014 201, 0332014201
0 332 014 203, 0332014203,
V23234C1004X017, V23234C1004Y017

Bosch Housing Number 3334485007

30 Amp Bosch Micro Relay 0332201107 SPDT 30/10
0 332 201 107
Your Cost
$15.75

30 Amp Bosch Micro Relay
0332201107 SPDT 30/10
30 Amp Rated NO Circuit
10 Amp Rated NC Circuit
75 OHM Resistor
SPDT 5 Terminals
12 Volts Coil Continuous Duty Replaces These Numbers
SONG CHUAN
871-1C-C-R1-U01-12VDC
Bosch,
0332201107896, 0332207300
0332207103, 0332207107,0332207307
0 332 201 107 896, 0 332 207 300
0 332 20 703, 0 332 207 107
0 332 207 307
Hella: 007814017
, 87109B
Tyco:
V23374A1601X008
V23374A1601Y008
V23374-A1601-Y008
V23374-A1601-Y008-EV

6 Volt SPDT Bosch Relay 0986AH0611
0986AH0611
Old Number

0 332 204 001

Your Cost
$38.50

Bosch Relay SPDT
6 volts
30 amps
85 Ohms
Continuous Duty
0332204001
Replaces Bosch 0332003002
0332003010 Old Number 0 332 204 001

Complete Kit 0986AHO611K


24 Volt SPDT Bosch Relay 0986AH0613
0986AH0613
0 332 204 203
Your Cost
$32.75

Bosch Relay
SPDT
20 Amp
24 VOLT DC Bosch Relay.

Bosch 0 986 AH0 613
5 Prong 24V Relay.
Features:NO & N C circuit.
NC 10 Amp & NO 20 Amp
Applications: Industrial applications.
0-986-AH0-613
Bosch Relay 0-332-204-203 24 Volt
Replaces
0332200014, 0-332-200-014
Bosch 0 332 200 014

24 Volt SPDT Bosch Relay 0 332 204 204
0986AH0614
0 332 204 204
Your Cost
$22.50

Bosch Relay
SPDT
20 Amp
24 VOLT DC Bosch Relay.

Bosch 0332204204 5 Prong 24V Relay.
Features: With Diode & NO & N C circuit.
NC 10 Amp & NO 20 Amp
Applications: many Industrial applications.
Complete Kit 0 332 204 204K
Bosch Relay 0-332-204-204 24 Volt

Please Specify if you need
12-10 ga Terminal
V23134-A7-Y936
V23134A7Y936
0-986-AH0-614
0 986 AHO 614
24 Volt SPDT Bosch Relay 0986AH0615
0986AH0615
0 332 204 201
Your Cost
$22.50

Bosch Relay
SPDT
20 Amp
24 VOLT DC Bosch Relay.

Bosch 0986AH0615 5 Prong 24V Relay.
Features: NO & N C circuit.
NC 10 Amp & NO 20 Amp
Applications: many Industrial applications.
Complete Kit 0986AH0615K
REPLACES Bosch 0332204201, 0-332-204-201
0332204202, 0 332 204 202
24 Volt
Please Specify if you need
12-10 ga Terminal

Click Here
For More Information
Bosch 24 Volt 10 Amp Relay 0 332 207 402

0 332 207 402
Your Cost
$16.75

24 Volt Bosch Micro Relay SPDT
10 Amp, W/Diode

5 Terminal
Duty Cycle: Intermittent
References:

Bosch 0332207201, 0332207202, 0332207402

0 332 207 201, 0 332 207 202, 0332207402
Tyco V23274-A2602-Y018
The 30AMRHK Relay Housing
For the Mini Relay With Mounting Hole. This 5 Prong Relay Housing With Terminals. Will Accommodate the Mini SPDT relays.
( 2 ) .250"& ( 3 ) .187" Terminals.
Please Specify if you need 10 ga terminals for the .250 blade term


Click On Image For
More Details

Bosch 12 Volt 50 Amp Relay 0 332 209 137

0 332 209 137
This Number is NLA
You May Use Song Chuan Relay Number
896H-1CH-C-R1-U03-12VDC
50 Amp 12 VOLT DC Power Relay.
This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
Continuous Duty
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

Relay Housing BRHKB With (5) Terminals.
Complete Kit 0332209137K
Can accommodate 10ga wire size.

Please Specify if you
need 12-10 ga Terminals.

Bosch Relay 0 332 209 137 12 Volt
0332209137 50 Amp Bosch Relay
Tyco V23234A0001X032
Bosch Housing 3 334 485 008
Bosch Housing Number 3334485008


Click On Image For
More Details

Bosch 12 Volt 50 Amp Relay 0 332 209 138
0 332 209 138
0 332 209 138 896
Your Cost
$21.5
0

50 Amp 12 VOLT DC Power Relay.
This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
Continuous Duty
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

Relay Housing BRHK With (5) Terminals.
Complete Kit 0332209138K
Can accommodate 10ga wire size .
Please Specify if you
need 12-10 ga Terminals.

Bosch Relay 0 332 209 138 12 Volt
Will Replace TYCO V23234A1001X033
0332209138896 New Number
0332209138 50 Amp Bosch Relay
Bosch Housing 3 334 485 007
Bosch Housing Number 3334485007
May use 0 332 019 110 4 Pin Relay if only 4 terminals are needed

Click On Image For
More Details

Bosch 12 Volt 30 Amp Relay 0 332 209 150

0 332 209 150
Your Cost
$9.75
30 Amp 12 VOLT DC Power Relay.
This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
Continuous Duty
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

Relay Housing BRHK With (5) Terminals.
Complete Kit 0 332 209 150K
Can accommodate 10ga wire size.

Please Specify if you
need 12-10 ga Terminals.

Bosch Relay 0 332 209 150 12 Volt
0332209150 30 Amp Bosch Relay
Replaces These Bosch Relays
0332100020, 0332200009, 0332200013, 0332204125, 0332204150, 0332204172
0332204801, 0332209150441 0332209150BLK, 36032, 36042
Tyco Numbers V23234A1001X036 V23234A1001Y036
Bosch Housing 3 334 485 007
Bosch Housing Number 3334485007

Click On Image For
More Details

Bosch 12 Volt 30 Amp Relay 0 332 209 151
0 332 209 151
Your Cost
$9.75

30 Amp 12 VOLT DC Power Relay.
This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
Continuous Duty
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

Relay Housing BRHKB With (5) Terminals.
Complete Kit 0 332 209 151K
Can accommodate 10ga wire size.

Please Specify if you need 12-10 ga Terminals.
Bosch Relay 0 332 209 151 12 Volt
0332209151 30 Amp Bosch Relay
Bosch Housing 3 334 485 008
Bosch Housing Number 3334485008

Bosch 12 Volt 0332209152 / 0 332 209 152 30 Amp SPDT with Diode
0 332 209 152
Your Cost
$13.50

30 Amp 12 VOLT DC Power Relay.
This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
Continuous Duty With Diode
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

Relay Housing BRHKB With (5) Terminals.
Complete Kit 0 332 209 152K
Can accommodate 10ga wire size.

Please Specify if you need 12-10 ga Terminals.
Bosch Relay 0-332-209-152 12 Volt
0332209152 30 Amp Bosch Relay
0332204122, 0332204122
0332204152, 0332209135,
033220915241
Tyco V23234A0001X038, V23234A0001Y038

Bosch 12 Volt 0332209158 / 0 332 209 158 30/20 Amp SPDT with Diode
0 332 209 158
Your Cost
$14.50

30 Amp 12 VOLT DC Power Relay.
This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
No Bracket,
Continuous Duty With Diode Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.
.
Complete Kit 0 332 209 158K
Can accommodate 10ga wire size.

Please Specify if you need 12-10 ga Terminals.
0 332 209 158
0332209158
V23234A1001X041
V2323A1001Y041

Bosch 12 Volt 0332209159 / 0 332 209 159 30/20 Amp SPDT with Resistor
0 332 209 159
Your Cost
$12.50

30 Amp 12 VOLT DC Power Relay.
This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
No Bracket,
Continuous Duty With Resistor Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.
.
Complete Kit 0 332 209 159K
Can accommodate 10ga wire size.

Please Specify if you need 12-10 ga Terminals.
Bosch Relay 0-332-209-159 12 Volt
0332209159 30/20 Amp Bosch Relay
0332209167,
Hella 007794027, 933332291

IHC 3607384C1
V23234-A0001-Y042



Click On Image For
More Details

Bosch 24 Volt 20 Amp Relay 0 332 209 203
0 332 209 203
Your Cost
$18.75
20 Amp 24 VOLT DC
Power Relay.

This 5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
SPDT
Continuous Duty
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.
Relay Housing BRHK With (5) Terminals.
Complete Kit 0332209203K
Can accommodate 10ga wire
size.

Please Specify if you
need 12-10 ga Terminals.

Bosch Relay 0 332 209 203 24 Volt
TYCO V23234A1004X050
0332209203 24 Volt Bosch Relay
Bosch Housing 3 334 485 007
Bosch Housing Number 3334485007

Click On Image For
More Details

Bosch 24 Volt 20 Amp Relay 0 332 209 204
0 332 209 204
Your Cost
$18.50

20 Amp 24 VOLT DC
Power Relay.
5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
SPDT.

Continuous Duty
With Diode
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.
Relay Housing BRHKB
Complete Kit 0332209204K
With (5) Terminals.
Can accommodate 10ga wire size.
Please Specify if you need 12-10 ga Terminals.
Bosch Housing 3 334 485 008
Bosch Housing Number 3334485008
Bosch Relay 0 332 209 204 24 Volt
0332209204 24 Volt Bosch Relay
Tyco Relays V23234A0004X051
V23234A0004Y051
May Replace
Hella 007903021

Click On Image For
More Details

Bosch 24 Volt 20 Amp Relay With Resistor 0 332 209 206

0 332 209 206
Your Cost
$8.75

20 Amp 24 VOLT DC
Power Relay.
5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
SPDT.

Continuous Duty With Resistor
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.
Relay Housing BRHKB With (5) Terminals.
Can accommodate 10ga wire size.
Please Specify if you need 12-10 ga Terminals.
Bosch Housing 3 334 485 008
Bosch Housing Number 3334485008
Replaces Bosch Relay 0332204206
0 332 204 206
24 Volt 0332209206
24 Volt Bosch Relay
Tyco V23234A0004X053

V23234A0004Y053

Click On Image For
More Details

Bosch 24 Volt 20 Amp Relay 0 332 209 211
0 332 209 211
Your Cost
$18.75


20 Amp 24 VOLT DC
Power Relay.
5 Prong Bosch Relay has many uses.
Features a NO & NC circuit.
SPDT.

Continuous Duty
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.
Relay Housing BRHKB With (5) Terminals.
Complete Kit 0332209211K
Can accommodate 10ga wire size.
Please Specify if you need 12-10 ga Terminals.
Bosch Housing 3 334 485 008
Bosch Housing Number 3334485008
Replaces Bosch Relay 0332204209
0 332 204 209
24 Volt 0332209211
24 Volt Bosch Relay
Tyco V2323A0004X055
,
V23234A0004Y055


0 333 009 002 24 Volt 150 Amp Continuous Duty
T-333 009 002
Your Cost
$88.50
Original Bosch $166.50

24 Volt 150 Amp Continuous Duty Bosch Replacement Type Solenoid
800 Amp Inrush
2 - 8mm Battery Studs
2 - 4mm Coil Activating Terminals
Nominal excitation current A 0,83

Dimensions L 104 x W 56 x H 57 mm
Mounting Base Flat 180 Degrees
Replaces Tyco V23333L0000X011
Bosch Number 0 333 009 002
333009002, 333 009 002
0333009002, 0-333-009-002


0 333 009 004 12 Volt 150 Amp Continuous Duty
T-333 009 004
Your Cost
$58.50
Original Bosch $192.50

12 Volt 150 Amp Continuous Duty
Bosch Replacement Type Solenoid

800 Amp Inrush
2 - 8mm Battery Studs
2 - 4mm Coil Activating Terminals
Nominal excitation current A 0,83

Dimensions L 104 x W 56 x H 57 mm
Mounting Base Flat 180 Degrees
Replaces Tyco V23333L0000X012
Bosch Number 0 333 009 004
0333009004,333009004, 333 009 004
0-333-009-004
Cole Hersee
Relays Continuous Duty & Intermittent Duty Relays 12 Volt and 24 Volt

"Click Here to View The Cole Hersee Relay Interchange Guide"


24037 12 Volt Motor Relay 750 Amp Inrush 100 Amp Current Carring Rating.
24037

Your Cost
$47.75
12 Volts Motor Relay Intermittent Duty
(2) 5/16"-24 Threaded Studs for Battery
Motor, (1) 10-32 Threaded Terminal for Activation, 8 mm x 15.1 mm Mounting Slots
56 mm Apart on Center,
750 Amp Inrush/ 100 Amp Carry Current Rating
Positive Activated Coil Circuit
.
This relay may be used to replace some of the numbers listed. Delco 1114532 Motorcraft 15-118, SWC5, SWX118
National Stock Number 2920009419748
Prestolite 15-123, 15-134, 15-136, 15-189, 15-232, 15-247, 15-250, SAE4001, SAE4005, SAE4005T, SAE4006, SAJ4005, SAS4203, SAS4203M, SAS4205, SAW4204, SAW4207


24039 6 Volt Motor Relay 750 Amp Inrush 100 Amp Current Carring Rating.
24039

Your Cost
Use 15-129
$46.50
6 Volts Relay
Intermittent Duty
Used on Delco 6 Volt Starters
(
2) 5/16"-24 Threaded Studs for Battery
Motor, (1) 10-32 Threaded Terminal for Activation, 8 mm x 15.1 mm Mounting: Curved Base
2.22in Radius (C222)
750 Amp Inrush/ 100 Amp Carry Current Rating
Positive Activated Coil Circuit, May Replace Delco Relay #

1119799, 1452, 1463, 1465, 1540, 1541, 1571, D926, D988
May Replace Prestolite / Ametek
15-129, 15-15, 15-28, 15-31, 15-67, 15-7, 15-74




24041 6 Volt Motor Relay 750 Amp Inrush 100 Amp Current Carring Rating.
24041

Your Cost
$57.50
6 Volts Relay
Intermittent Duty
(
2) 5/16"-24 Threaded Studs for Battery
Motor, (1) 10-32 Threaded Terminal for Activation, 8 mm x 15.1 mm Mounting Slots
56 mm Apart on Center,
750 Amp Inrush/ 100 Amp Carry Current Rating
Positive Activated Coil Circuit
.


24047 12 Volt Motor Relay 750 Amp Inrush 100 Amp Current Carring Rating.
24047

Your Cost
$49.50


12 Volts Relay Intermittent Duty
Insulated Coil Circuit
(2) 5/16"-24 Threaded Studs for Battery Motor, (1) 10-32 Threaded Terminal for Activation, 8 mm x 15.1 mm Mounting Slots
56 mm Apart on Center,
750 Amp Inrush/ 100 Amp Carry Current Rating

12 Volt Power Up Relays to remove loads from Ignition Switches
24059
Your Cost
$48.75


12 Volt DC Universal Applications:
Power Up Relays to remove loads from Ignition Switches,
Electric Cooling Fans, and much more.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 85 Amp

Insulated Coil Circuit


Click Here To View Drawing"
24060 12 Volt Motor Relay 750 Amp Inrush 100 Amp Current Carring Rating.
24060

Your Cost
$42.50






12 Volts Motor Relay
Intermittent Duty
(2) 5/16"-24 Threaded Studs for Battery
Motor, (1) 10-32 Threaded Terminal for Activation, 8mm x 15.1mm Mounting Slots
56mm Apart on Center,
750 Amp Inrush/ 100 Amp Carry Current Rating
Ground Activated Coil Circuit
.

24 Volt Power Up Relays to remove loads from Ignition Switches
24063
Your Cost
$53.50

24 Volt DC Universal Applications:
Power Up Relays to remove loads from Ignition Switches, Hydraulic Pump Motors ,Electric Cooling Fans, and much more.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Copper
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 85 Amp



24063-08 24 Volt 85 Amp Plasticized Housing Power Up Relays to remove loads from Ignition Switches
24063-08
Your Cost
$71.50

24 Volt DC Universal Applications:
Power Up Relays to remove loads from Ignition Switches, Hydraulic Pump Motors ,Electric Cooling Fans, and much more.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Copper
Voltage Rating 24V DC
Plasticized Housing
UL Listing
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 85 Amp



24082  12 Volt Continuous Duty Insulated Coil Circuit.
24082
Your Cost
$51.50

Prestolite, Ametek
12 Volts Continuous Duty
3 Terminal, Grounded Case
100 Amp Current Rating
(2) 5/16-18 Motor & Battery Studs
(1)10-32 Threaded Terminal
Curved 2.22 base
.
AmetekPrestolite SAS-4209
Delco 1114227
National Stock Number 5945012092843
Navistar ZN24082
15-140, SAS4209


24097  6 Volt Continuous Duty Insulated Coil Circuit.
24097
Your Cost
$59.50

Prestolite, Ametek
6 Volts Continuous Duty
4 Terminal, Insulated Case
Coil Winding 2.5-3.5 ohms
100 Amp Current Rating
(2) 5/16-18 Motor & Battery Studs
(2)10-32 Threaded Terminal
Flat Mounting Base
May Replace Prestolite Ametek
Prestolite SAS4601,
Ametek 15-144, SAS-4601
May Replace White Rodgers
70-180224-5A, 70-901,
70-901, 70-901S1 & replaces
70-108225-5A 70-913 Stancor
With The Addition of a Jumper Ground Wire.

12 Volt Starter Relays With Ignition Bypass Terminal.
24103
Your Cost
$58.50

12 Volt 4 Terminal
Grounded Case
With Ignition Bypass Terminal
Or "R Terminal Activation"
Commonly used in engine starting applications.
Intermittent Duty
750A make, 100A break,
10sec On, 20min Off.
Contacts: Copper.
Terminals: Copper. Small terminals are 10-32 thread.
Large contact terminals are 5/16" -24 thread.
Bracket mounting holes
5/16 x 19/32,” 2 13/64" on centers (7.9 x 15.1, 56.0mm)
Plated steel housing.


Power Up Relays to remove loads from Ignition Switches
24106
Your Cost
$48.50

12 Volt Universal Application:
Power Up Relays to remove loads from Ignition Switches, Electric Cooling Fans,
and much more.
Ground Case Circuit
Normally Open Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 85 Amp
Replaces Prestolite 15-139, SAS-4208
White Rodgers W/R 70-914
70-111225-5A

12 Volt 85 Amp Continuous Duty Relay Ground Activated
24115
Your Cost
$59.50
12 Volts Continuous Duty Relay
Number of Terminals: 3
Continuous Duty,
(2) 5/16"-24 Threaded Studs for Battery & Motor
(1) 10-32 Threaded Terminal for Activation,
8mm x 15.1mm Mounting Slots-56mm Apart on Center, 85 Amp Carry Current Rating
Continuous Duty Rating 85 Amp
Ground Activated Coil Circuit
May Replace White Rodgers
70-11226 , 70-11226-5A, 70-918
12 Volt 85 Amp Continuous Duty Relay Plasticized Housing .
24117
Your Cost
$65.50

12 Volts Continuous Duty Relay
Number of Terminals: 4
Continuous Duty,
(2) 5/16"-24 Threaded Studs for Battery & Motor
(1) 10-32 Threaded Terminal for Activation,
8mm x 15.1mm Mounting Slots-56mm Apart on Center, 85 Amp Carry Current Rating
Continuous Duty Rating 85 Amp
Plasticized Housing
for Exposure Protection

24 Volt Power Up Relays to remove loads from Ignition Switches
24124

Your Cost
$51.50


24 Volt Special Applications Grounded Case
NO normally open
Circuitry SPST
Contacts: Copper
Housing plated steel
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Hex nuts and lock washers included
Continuous Duty Rating 85A Maximum Current,
Make 120A Maximum Current, Break 65A Intermittent Time Not Bracket Straight
Bracket Mounting Holes
5/16" x 19/32" 2-13/64" on center
C/U SAS-4414 SAS4414 Ametek
15-419 .

Click Here To View Drawing"
"Click Here To View Drawing"
24200
Your Cost
$119.50
Latching Relay
Special Applications:
"Remotely-Operated Battery Isolator,
Remote Battery Disconnect Switch"
Insulated Ground
Normally open or normally closed
Circuitry SPST
Contacts : Copper
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 110 Amp
"Use Momentary Type Switch To Activate Relay"





Power Up Relays to remove loads from Ignition Switches
24213
Old Number 24143
Your Cost
$114
.50

12 Volt High Current Applications:
Power up relays to remove loads from Ignition Switches, Electric Cooling Fans,and ,any more applications.
Insulated Ground
Normally Open Circuit Circuitry SPST
Contacts : Silver
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 200 Amp
Can be used to Replace Delco 1114218, 1114223, Prestolite 15-132, 15-133, 15-236, SAS-4201,
SAS-4202, SAS-4213, SAS-5203

Replaces 24143


24 Volt 200 Amp Power Up Relay Continuous Duty.
24214
Old Number 24144
Your Cost
$113.50


24 Volt DC Universal Applications:
Power Up Relays to remove loads from Ignition Switches, Pump Motors ,High Current Utility Vehicles, Winches, Lift Trucks, Hydraulic Pumps Snow Plows etc.
Insulated Ground Circuit
Normally Open Circuitry SPST
Contacts : Silver
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating 200 Amp
Can be used to Replace
Prestolite 15-141, 15-196, 15-310,
SAS-4401, SAS-4408, SAS-5401



Forward & Reverse Systems Winches, Golf Carts
24401
Your Cost
$71.50


12 Volt Special Applications
"Forward & Reverse Systems Winches, Golf Carts" Insulated Ground
Circuit
Normally Open Circuit 85 Amp
Normally Closed Circuit 35 Amp

Circuitry SPDT
Contacts : Copper
Housing : plated steel
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating


Forward & Reverse Systems Winches, Golf Carts
24402
Your Cost
$78.50
24 Volt Special Applications
"Forward & Reverse Systems, Winches Golf Carts" Insulated Ground
Normally Open Circuit 85 Amp
Normally Closed Circuit 35 Amp

Circuitry SPDT
Contacts : Copper
Housing : plated steel
Voltage Rating 24V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
Continuous Duty Rating.

























T24450-12S 12 Volt
Reversing Relay

Replaces
Cole Hersee 24450 & 24450-01

12 Volt DC Reversing Solenoid:
Used for permanent magnet motors.
Such as winches,Hoist Any Reversible permanent magnet motor.
No need to use the (4) SPST Relays or the
(2) SPDT Relays with this New
Reversing Solenoid .
Voltage: 12V DC.
Max operating voltage 14.5V DC.
DPDT Intermittent Duty.
Contacts: Silver
Flat Base bracket
Large studs: 5/16" -24
Coil terminals: two blades
Coil type: common ground
Two integral solenoids provide dynamic braking for permanent magnet motors when neither coil is energized.
12V DC 75A make and break,
max On time 5min.
12V DC 125A make and break,
max On time 30sec.
12V DC 150A make and break,
max On time 0.5sec.
Allow 5min Off after max On time.
12 Volt DC Reversing Solenoid
All Specifications are the Same as the 24450
With Silver Contacts.
Trombetta
214-1211A11, 214-1211A11-06,
214-1211A51, 214-1211A61,
214-1231A11
214-1211-A11, 214-1211-A11-06,
214-1211-A51, 214-1211-A61,
214-1231-A11

Use with a SPDT momentary toggle or rocker switch:
Toggle Switch (such as 55021)

T24450-24 24 Volt
Reversing Relay

Replaces Cole Hersee 24450-01
24
Volt DC Reversing Solenoid:
Used for permanent magnet motors.
Such as winches,Hoist Any Reversible permanent magnet motor.
No need to use the (4) SPST Relays or the (2) SPDT Relays with this New
Reversing Solenoid .
Voltage: 24V DC.
Max operating voltage 28.5V DC.
DPDT Intermittent Duty.
Contacts: Silver Alloy Plating
Flat Base bracket.
Large studs: 5/16" -24
Coil terminals: two .250 blades
Coil type: common ground
Two integral solenoids provide dynamic braking for permanent magnet motors when neither coil is energized.
24V DC 75A make and break,
max On time 5min.
24V DC 100A make and break,
max On time 30sec.
24V DC 150A make and break,
max On time 0.5sec.
Allow 5min Off after max On time. Use with a SPDT momentary toggle or rocker switch:
Toggle Switch (such as 55021)



For More Information
Click Here

12 Volt DC Forward & Reverse Relay Module. Click Here For More Information.
24452

Your Cost
$120.79



Wireless Remote Module 12 Volt Wireless Remote Module Can be Used with The 24450 & 24452 Reversing Relay Modules.As well as other Reversing Winch Circuits.
WRM
Your Cost

$64.50

This Remote Module Can be Used
with The 24450 & 24452

Reversing Relay Modules.
Can Be used With Any 12V SPDT Relays
Wired to work Reversing Polarity Circuit.
Operation : Off-No Switch.

Push the IN button the relay activates in a momentary activation.
STOPS when you let off of the button.
Push the OUT button the relay activates in a momentary activation
.
STOPS when you let off of the button.
Red Wire = 12V + Positive
Black Wire = -- Negative
White = OUT Function
Yellow = IN Function
Blue = Antenna

Working range up to 30 feet


12 Volt DC Forward & Reverse Relay Module
Carries a heavy load current.
• Fully sealed – can withstand very harsh environments.
• Intermittent or continuous operation.
Use on Small Winches & other reversing applications.
Module reverses the direction of the motor when the appropriate control circuit is energized with a pulse from a control switch.
Low-profile module saves space.
Studs are securely anchored in epoxy.
2.91"× 3.51" × 1.86" H (73.9 × 91.7 × 47.2mm)
Specifications
• High performance silver tin oxide contacts.
70A at 12V DC intermittent, max On time 5 mins;
Off time 3 mins; 50A at 12V DC continuous.
Load current inrush: 150A. Pull-in voltage 7.8V max.
• Low coil current draw. Coil resistance 82? ±10%.
• Vibration resistance: 10-55Hz. Double amplitude 1.5mm. • Environmental: -40C to 85C.
Rust and moisture-resistant plastic housing.
• Fully sealed to IP-67 with high strength epoxy for total moisture protection. • Ignition protected. • Tin-plated brass studs and hardware for corrosion resistance. • Dielectric strength: 500V RMS between coil and contact. • For intermittent operation, control switch should be Mom On-Off-Mom On; for continuous operation On-Off-On.
Toggle Switch
(such as 55021)

Cole Hersee 12 Volt Continuous Duty Relay 100A
24512-10
Your Cost
$62.50

12 Volt DC
Continuous Duty
Universal Applications: Power Up Relays to remove loads from Ignition Switches, Including Lawn Tractors,Golf Carts, Electric Cooling Fans, and much more.
Insulated Coil Ground

Normally Open Circuitry SPST
Contacts : Silver
Voltage Rating 12V DC
(2) 5/16"-24 thread
(2) 1/4 " Blade Terminals
Continuous Duty Rating 100 Amp
400A Inrush






24612

Your Cost
$63.50

12 Volt DC Continuous Duty
Universal Applications: Power Up Relays to remove loads from Ignition Switches, Including Lawn Tractors,Golf Carts, Electric Cooling Fans, and much more.
Insulated Coil Ground

Normally Open Circuitry SPST
Contacts : Silver
Voltage Rating 12V DC
(2) Terminals copper; 10-32 thread
and (2) 5/16"-24 thread.
Continuous Duty Rating 100 Amp
400A Inrush



12 Volt Continuous Duty Rating 100 Amp Power Up Relays to remove loads from Ignition Switches
24612-10

Your Cost
$62.50

12 Volt DC Continuous Duty
Universal Applications: Power Up Relays to remove loads from Ignition Switches, Including Lawn Tractors,Golf Carts, Electric Cooling Fans, and much more.
Insulated Coil Ground
Normally Open Circuitry SPST
Contacts : Silver
Voltage Rating 12V DC
(2) Terminals copper; 10-32 thread
and (2) 5/16"-24 thread.
Continuous Duty Rating 100 Amp
400A Inrush

12 Volt Continuous Duty Rating 100 Amp Power Up Relays to remove loads from Ignition Switches
24612-G10

Your Cost
$61.50

12 Volt DC Continuous Duty
Universal Applications: Power Up Relays to remove loads from Ignition Switches, Including Lawn Tractors,Golf Carts, Electric Cooling Fans, and much more.
Flat Ground Base Circuit
Normally Open Circuitry SPST
Contacts : Silver
Voltage Rating 12V DC
(1) Terminal copper; 10-32 thread
and (2) 5/16"-24 thread.
Continuous Duty Rating 100 Amp
400A Inrush

May Be used To Replace
Camdec Corp # 93285




Click Here For More Information
24812 - 12 Volt 225 Amp Continuous Carry Rating, 600 Amp Inrush.

24812
USE

114-1211-020-02
Your Cost
$103.50


12 Volt Continuous Duty
Special Applications: USED AS BATTERY
DISCONNECT SWITCH AND FOR EXTRA HEAVY DUTY ELECTRICAL LOADS.
USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS .
Amps: 225 With 600 Amp Inrush.
Coil Type: Isolated
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material: Copper
Duty Cycle: Continuous
Can Be used to replace
Trombetta
114-1211-010
Camdec Corp, PN # 18226-WR
12 Volt Continuous Duty


Click Here For More Information
24812-01 -12 Volt 225 Amp Silver Contact Continuous Carry Rating, 600 Amp Inrush.

24812-01
USE
114-1211-020-02


12 Volt Continuous Duty
Special Applications: USED AS BATTERY
DISCONNECT SWITCH AND FOR EXTRA HEAVY DUTY ELECTRICAL LOADS.
USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE FIRE TRUCKS,
SCISSOR LIFT, GOLF CARTS,HYDRAULIC PUMPS SYSTEMS ,BOOM LIFTS TRUCKS.
Amps: 225
With 600 Amp Inrush.
Coil Type: Isolated
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material: SILVER
Duty Cycle: Continuous

Can Be used to replace
Trombetta 114-1211-020-02
Click Here For More Information
24824-01 - 24 Volt 225 Amp Silver Contact Continuous Carry Rating, 600 Amp Inrush.

24824-01

Your Cost
$110.00

24 Volt Continuous Duty
Special Applications: USED AS BATTERY
DISCONNECT SWITCH AND FOR EXTRA HEAVY DUTY ELECTRICAL LOADS.
USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE FIRE TRUCKS,
SCISSOR LIFT, GOLF CARTS,HYDRAULIC PUMPS SYSTEMS ,BOOM LIFTS TRUCKS.
Amps: 225
With 600 Amp Inrush.
Coil Type: Isolated
Coil Volts DC: 24 DC
Contact Form: SPNO
Contact Material: SILVER
Duty Cycle: Continuous

Can Be used to replace Trombetta
114-2411-020
Click Here For More Information
24 Volt 20 Amp SPDT Relay Available With  and Without Diode.

RC200124DN
Your Cost
$8.50

RC200124NN
No Coil Features
Your Cost
$8.50


24 Volt 20 Amp
Cole Hersee Mini Relay

SPDT
Cap Material = Plastic

Unsealed Housing
5 Terminals
# 85 .250
# 86 .250
# 30 .250"
# 87 .250
# 87a .250
24 Volts
20 Amp Continuous Duty.
Resistance Features = Diode

Resistance Ohms = 100 Ohms
With Removable Mounting Bracket
To be used with 30RHKB
0 332 209 204, 0332209204 Bosch

May Replace bosch 0 332 204 213,
0223204213

24 Volt 20 Amp SPDT Relay Available With  and Without Resistor.
RC200124RN
Your Cost
$8.50


24 Volt 20 Amp
Cole Hersee Mini Relay

SPDT
Cap Material = Plastic

Unsealed Housing
5 Terminals
# 85 .250
# 86 .250
# 30 .250"
# 87 .250
# 87a .250
24 Volts
20 Amp Continuous Duty.
Resistance Features Resistor

Resistance Ohms = 100 Ohms
With Removable Mounting Bracket
Can Replace SONG CHUAN 896H-1CH-D1-R1
896H 1CH D1 R1

40 Amp SPST Relay with Diode
RA400012DS
To be Discontinued
Your Cost
$8.75

12 Volt 40 Amp
Cole Hersee Mini Relay

SPST
Cap Material = Plastic

Sealed Housing
4 Terminals
# 85 .250
# 86 .250
# 30 .250"
# 87 .250
12 Volts
40 Amp Continuous Duty.
Resistance Features = Diode

Resistance Ohms = 100 Ohms
No Mounting Bracket

To be used with
30RHKB

Click On Part Number Below To View Drawing
Click On The Part Numbers for More Relay Information
RA400112NN

Your Cost
$8.75
RA400112RN $9.50
RA400112DN $9.75


12 Volt 40 Amp Cole
Hersee Mini Relay

SPST
Includes Mtg Bracket

Cap Material = Plastic
4 Terminals
# 85 .250
# 86 .250
# 30 .250"
# 87 .250
12 Volts
Continuous Duty
Resistor & Diode Models Available.

Order RN for Resistor Relay
Order RD for Diode Relay
Tyco / Potter Brumfield
VF4-11F11,

Click On Part Number Below To View Drawing
Click On The Part Numbers for More Relay Information
RC400112NN

Your Cost
$9.50

RC400112RN $9.75
RC400112DN $8.75


12 Volt 40 Amp
Cole Hersee Mini Relay

SPDT
Cap Material = Plastic

5 Terminals:
# 85 .250
# 86 .250
# 30 .250"
# 87 .250
# 87a .250
12 volts
Continuous Duty
Includes Mtg Bracket
Unsealed
Can Be wired to be used for small permanent magnet motors. Electric Door Lock Motors, Small Reversible Permanent Magnet Motor.
Resistor & Diode Models Available.

Order RN for Resistor,
Replacement for
Bosch 0 332 204 159
Order DN for Diode Relay
Tyco / Potter Brumfield
VF4-15F11
Click Here To View Drawing
70 Amp Cole Hersee High Capacity Mini Relay.
RA700112NN
Your Cost
$12.50

RA700112RN
Your Cost
$12.75

RA700112DN
W/DIODE
Your Cost
$13.00




12 Volt 70 Amp Cole Hersee
High Capacity Mini Relay

SPST
Includes Metal Mtg Bracket

Cap Material = Plastic
4 Terminals
# 85 .250
# 86 .250
# 30 .375"
# 87 .375
12 Volts
70 Amps
Continuous Duty

AVAILABLE IN RESISTOR
RA700112RN
RA70112NN May Replace Tyco / Potter Brumfield VF7-11F11, VF711F11
VF7-41F11 , VF741F11

Click Here To View Drawing
70 Amp Cole Hersee High Capacity Mini Relay.
RC700112NN
Your Cost
$14.50


12 Volt 70 Amp Cole Hersee
High Capacity Mini Relay

SPDT
Cap Material = Plastic

5 Terminals:
# 85 .250
# 86 .250
# 30 .375"
# 87 .375
# 87a .375
12 volts
70 amps
Continuous Duty
Includes Mtg Bracket
Unsealed
Can Be wired to be used for permanent magnet motors.
Such as Small Winches,
Small Hoist Small Reversible Permanent Magnet Motor

Click Here To View Drawing
70 Amp Cole Hersee High Capacity Mini Relay.
RC700112RN
Your Cost
$13.75


12 Volt 70 Amp
Cole Hersee High Capacity Mini Relay
High Capacity Mini Relay
SPDT 5 Prong
Cap Material = Plastic
5 Terminals:

# 85 .250
# 86 .250
# 30 .375"
# 87 .375
# 87a .375

12 volts
70 amps
100 Ohms Resistance Features
Continuous Duty
Includes Mtg Bracket
Unsealed

Can Be wired to be used for permanent magnet motors.
Such as Small Winches, Small Hoist
Any Small Reversible Permanent Magnet Motor.



Click Here To View Drawing

12 Volt 30 Amp Relay kit, comes with Relay, Relay Housing & 5 Relay Housing Terminals.
30ARK
Relay Kit $16.75

W/Resistor or Diode
Relay Kit $18.75



30 Amp 12 VOLT DC Power Relay
This 5 Prong Bosch Type Relay has many
Automotive uses.
Features a NO & NC circuit. ( SPDT )
Applications: May be used to power,Medium
Size Electric Cooling Fans, Driving Lights,
Electric Door Locks much more.
Relay Housing 30ARHK With (5) Terminals.
Complete Kit 30ARK
Can accommodate to 10ga wire
size.

Please Specify if you need
12-10 ga Terminals.


Relays are Available with
Resistor or with Diode.


Click Here To View Drawing

May be used to power,Medium Size Electric Cooling Fans, Driving Lights,& much more
30ARKB
Relay Kit $15.75
W/Resistor or Diode

Relay Kit $16.75

30
Amp 12 VOLT DC Power Relay Kit 30ARKB
Relay & Housing With Terminals.
Will Accommodate the 4 prong
SPST
& 5 Prong 30 amp SPDT relays.

A
pplications: May be used to power, Electric Cooling Fans, Driving Lights, Much more.
Relay Housing With Mounting Tab 30RHKB
Comes with( 5 ) .250" Terminals
These Relay Housings can be stacked side by side.
Bosch Relay Housing 3 334 485 008

Please Specify if you need
12-10 ga Terminals.


Relays are Available with
Resistor or with Diode.
12 Volt 70 Amp Heavy Duty .375 Blade Relay Kit With Housing and 4 Terminals.
70ARK
Your Cost
$26.50


70
Amp 12 VOLT DC Power Relay Kit 70ARK
This 4 Prong Relay & Relay Housing With Terminals.
Will Accommodate the 4 prong 70 amp SPST relays.
Applications: May be used to power,larger Size Electric Cooling Fans, Driving Lights, Much more.
Relay Housing With Mounting Tab .
70RHK With (4 ) Terminals.
Comes with( 2 ) .250" & ( 2 ) .375" Power Terminals
Can accommodate to 8 ga wire size.

Please Specify if you need 8 ga Terminals

AVAILABLE IN RESISTOR

70ARK-RN


12 Volt 70 Amp Heavy Duty .375 Blade Relay Kit With Housing and 4 Terminals.
70ARKB
Your Cost
$26.50


70 Amp 12 VOLT DC Power Relay Kit 70ARKB
This 4 Prong Relay & Relay Housing With Terminals.
Will Accommodate the 4 prong 70 amp SPST relays.
Applications: May be used to power,larger Size Electric Cooling Fans, Driving Lights, Much more.
Relay Housing With Mounting Tab .
70RHB With (4 ) Terminals.
Comes with( 2 ) .250" & ( 2 ) .375" Power Terminals
Can accommodate to 8 ga wire size.
These Relay Housings can be stacked side by side.

Please Specify if you need 8 ga Terminals.

AVAILABLE IN RESISTOR
70ARKB-RN

70 Amp Relay Housing Without  Mounting Hole and 4 Terminals.
70ARHK
Your Cost
$14.75


70 Amp Relay Housing With Mounting Hole.
This 4 Prong Relay Housing With Terminals.
Will Accommodate the 4 prong 70 amp SPST relays.
Applications: May be used to power,larger Size Electric Cooling Fans, Driving Lights Much more.
70ARHK With (4 ) Terminals.
Comes with( 2 ) .250" & ( 2 ) .375" Power Terminals
Can accommodate to 8 ga wire
size.
Please Specify if you need 8 ga Terminals.

70 Amp Relay Housing With Mounting Hole and 4 Terminals.
70ARHKB
Your Cost
$14.50

70
Amp Relay Housing With Mounting Hole.
This 4 Prong Relay Housing With Terminals.
Will Accommodate the 4 prong 70 amp SPST relays.
Applications: May be used to power,larger Size Electric Cooling Fans, Driving Lights Much more.
70RHKB With (4 ) Terminals.
Comes with( 2 ) .250" & ( 2 ) .375" Power Terminals
Can accommodate to 8 ga wire
size.
These Relay Housings can be stacked side by side
Please Specify if you need 8 ga Terminals.


70 Amp SPDT Relay Housing With Mounting Hole and 5 Terminals.
70ARHKB-DT
Your Cost
$19.50
70 / 80 Amp Relay Housing
With Out Mounting Hole.
This 5 Prong Relay Housing With Terminals. Will Accommodate the 5 prong 70 amp SPST relays.
Applications: May be used to power,larger Size Electric Cooling Fans, Driving Lights Much more.
70RHKB-DT With (5 ) Terminals.
Comes with( 2 ) .250" & ( 3 ) .375" Power Terminals
Can accommodate to 8 ga wire
size.
These Relay Housings can be stacked side by side
Please Specify if you
need 8 ga Terminals.


70 Amp SPDT Relay Housing and 5 Terminals.
70ARHK-DT
Your Cost
$18.50

70
Amp Relay Housing With Mounting Hole.
This 5 Prong Relay Housing With Terminals. Will Accommodate the 5 prong 70 amp SPST relays.
Applications: May be used to power,larger Size Electric Cooling Fans, Driving Lights Much more.
70RHK-DT With (5 ) Terminals.
Comes with( 2 ) .250" & ( 3 ) .375" Power Terminals
Can accommodate to 8 ga wire
size.
These Relay Housings can be stacked side by side
Please Specify if you
need 8 ga Terminals.

Relay Housing For the Bosch Relay With PC Board Mounting Solder Connections.
PCBRH
Your Cost
$8.50



Relay Housing For the Bosch Relay With PC Board Mounting Solder Connections.
This 5 Prong Relay Housing With Terminals.
Will Accommodate the SPDT relays.
( 2 ) .250" & ( 3 ) .250" Terminals
3334485010, 3 334 485 010
V23333Z0002A010
5 Pin Relay Housing With 14ga Power Leads Pigtail
BRPT

Your Cost
$21.50



5 Pin Relay Housing
With 3 = 12ga power Leads
Can be used with all Bosch Relays
& Cole Hersee Relays,
Hella Time Delay Relays as well
5 & 4 Terminals 30 / 50 Amp
5 = .250 / 1/4" Terminals

5 Pin Relay Housing With 16ga Leads Pigtail
BRHPTB
Your Cost
$6.50





5 Pin Relay Housing With 16ga Leads With Mounting Hole in Base.
Can be used with all Bosch Relays & Cole Hersee Relays,
Hella Time Delay Relays as well 5 & 4 Terminals 30

5 = .250 / 1/4" Terminals.

30 Amp Rated Micro Relay Housing SPDT 5 Terminals .
30AMRHK

Your Cost
$8.75

Relay Housing For the 25-30 Amp Mini & Micro Relays
With Mounting Hole.
This 5 Prong Relay Housing With Terminals.
Will Accommodate the Mini SPDT relays.
( 2 ) .250" & ( 3 ) .187" Terminals
Can accommodate to 10 ga wire
size.
Please Specify if you
need 10 ga Terminals.

Bosch Housing 3334485045





Hella Relays & Hella Weatherproof
Continuous Duty Relays & Water Restraint Sockets

Hella 003530001 15 Amp Hella Relay  SPST With 15 Amp Fuse
003530001
Your Cost $28.50

Click Here For More Information

Hella 15Amp 12 VOLT DC
Mini Power Relay.
This 4 Prong Hella
With Mounting Bracket
Includes 15A Fuse
Features a NO Circuit.
15A NO Circuit
# 85 .250
# 86 .250
# 30 .375"
# 87 .375

Continuous Duty
Applications: May be used to power,Small Electric Cooling Fans
Driving Lights,used in many
Industrial applications.

May Replace Other Hella Numbers
003510361, 4RA003530-00,
87105, 87108
John Deere AZ55251
Mitsubishi Z1519800

Hella 007903021 24 Volt Hella 20 Amp SPDT Relay with Diode
007903021
Your Cost $15.50

20 Amp 24 VOLT DC
Power Relay.
5 Prong Hella Relay has many uses.
Features a NO & NC circuit.
SPDT.

Continuous Duty
With Diode
Driving Lights,used in many Industrial applications.
Relay Housing BRHKB
Complete Kit 007903021K
With (5) Terminals.
Can accommodate 10ga wire size.
Please Specify if you need 12-10 ga Terminals.
Bosch Housing 3 334 485 008
Bosch Housing Number 3334485008
Will Replace Bosch Relay
0 332 209 204
24 Volt
0332209204 24 Volt Bosch Relay
Tyco Relays V23234A0004X051
V23234A0004Y051
Replaces
Hella 4RD003520-15 4RD00790302, 4RD 007 903-02

Hella 007793031 Hella 70 Amp SPST Relay with Resistor
007793031
Your Cost $21.75
Hella 70 Amp 12 VOLT DC
Heavy Duty Power Relay.
This 4 Prong Hella Relay has many uses. Without Mounting Bracket
Features a NO Circuit.
70A NO Circuit
# 85 .250
# 86 .250
# 30 .375"
# 87 .375

Continuous Duty W/Resistor
Applications: May be used to power Electric Cooling Fans Driving Lights,used in many Industrial applications.

May Replace Other Hella Numbers
00351070, 4RA007793-03, 87432, H4151015,
John Deere AL207376
Massey Ferguson, 4270844M1
Tyco Number VF7-11F11S01
Can Use 70ARHK Relay Housing Kit

Hella 007793041 Hella 50 Amp SPST Relay with Resistor
007793041
Your Cost $21.75
Hella 50 Amp 12 VOLT DC
Heavy Duty Power Relay.
This 4 Prong Hella Relay has many uses.
With Mounting Bracket
Features a NO Circuit.
50A NO Circuit
# 85 .250
# 86 .250
# 30 .375"
# 87 .375

Continuous Duty W/Resistor
Applications: May be used to power,Medium Size Electric Cooling Fans
Driving Lights,used in many
Industrial applications.

May Replace Other Hella Numbers
003510511, 4RA00351051, 4RA007793041, 87430, H41510141
Bosch 0 332 002 190
0332002190
0332002192
0 332 002 192
John Deere AL208595
Massey Ferguson 3387326M2
Use 70ARHK Relay Housing Kit

Hella 00779041 Hella 40 Amp SPDT Relay with Diode.
007794041
Your Cost $14.50
Hella 40 Amp 12 VOLT DC Power Relay.
This 5 Prong Hella Relay has many uses.
No Bracket
Features a NO & NC circuit.
40A NO Circuit / 30A NC Circuit
Continuous Duty W/Diode
Applications: May be used to power,Medium Size Electric Cooling Fans
Driving Lights,used in many
Industrial applications.

May Replace Other Hella Numbers
4RD00352025, 4RD007794-04, 87104, 87410, 87424, H41388251, H41388641, H4152019, Bosch Relay 0332209135
0 332 209 135, 0-332-209-135.
Tyco Relay VF4-15F11S05,VF4-15F11-S05 SEMENS
VF4-15F21S05
Click Here
For More Information

Hella 00794301 Hella 40 Amp SPDT Relay.
007794301
Your Cost $17.95
Hella 40 Amp 12 VOLT DC Power Relay.
This 5 Prong Hella Relay has many uses.
Features a NO & NC circuit.
40A NO Circuit / 30A NC Circuit
Continuous Duty W/Resistor
Weatherproof Skirt
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

May Replace Other Hella Numbers
4RD007794-30, 4RD 007 974 301
87411, 87414, H41388151, H41388221
May replace GM # 25530904
Our Information shows that this Relay will Replace Other Hella Numbers
HL87411, 87411 H41388311 4RD 960 388-31 4RD960388-31, 007794311, 7794311, TYCO VF4-65F11-S01

0332204185 , 0-332-204-185
Click Here
For More Information

Hella 00794311 Hella 40 Amp SPDT Relay.
007794311
Your Cost $17.75
Hella 40 Amp 12 VOLT DC Power Relay.
This 5 Prong Hella Relay has many uses.
Features a NO & NC circuit.
40A NO Circuit / 30A NC Circuit
Continuous Duty W/Resistor
Weatherproof Skirt
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

May Replace Other Hella Numbers
87412, H41388311, 7794311,
H41388151,

Click Here
For More Information

Hella 00794321 Hella 40 Amp SPDT Relay.
007794321
Your Cost $16.50
Hella 40 Amp 12 VOLT DC Power Relay.
This 5 Prong Hella Relay has many uses.
Features a NO & NC circuit.
40A NO Circuit / 30A NC Circuit
Continuous Duty W/Resistor
Weatherproof Skirt
Applications: May be used to power,Medium Size Electric Cooling Fans, Driving Lights,used in many Industrial applications.

May Replace Other Bosch & Hella Number
And Some GM Vehicle Applications
Bosch 0332204185
Hella 007794327, 4RD007794-32
4RD 007 794-32, 4RD960388-13, 87405, 87408, 87413, H41388061, H41388131, H41388321


Hella 12 Volt Realy 931680011 Hella 40/20 Amp SPDT Relay.
931680011
Your Cost $19.75
Hella 40 Amp 12 VOLT DC
Power Relay 5 TERMINAL .
Features a NO & NC circuit.
40A NO Circuit / 20A NC Circuit
Continuous Duty
W/ 680 OHM Resistor
Heavy Duty And Industrial applications.

May Replace Other Hella Numbers
4RD93168001 , 87102, 87429 ,
H41388061, H41680011, 931680017

Click Here
For More Information

Hella 24 Volt Realy 933332201 Hella 20 Amp SPDT Relay.
933332201
4RD 933.332.201
Can Use This Number Also
933332207
Your Cost $19.75





Hella 24 Volt 20 Amp DC
Power Relay
Features a NO & NC circuit.
20A NO Circuit / 10A NC Circuit
Continuous Duty W/Resistor
May Replace Other Hella Numbers 4RD933332-20, 87421 H41388541
4RD 933332-20 HL 87421B
4RD 960 388-54
4RD 933.332.201
960388547
933332207

Tyco Relay Numbers.
VF4-65H11S08, VF4-65H21S08
Can Use 933332207





Click Here
For More Information

Hella 24 Volt Realy 933332207 Hella 20 Amp SPDT Relay.
933332207
4RD 933.332.207
Can Use This Number Also
933332201
Your Cost $16.75

Hella 24 Volt 20 Amp DC
Power Relay
Features a NO & NC circuit.
20A NO Circuit / 10A NC Circuit
Continuous Duty W/Resistor
May Replace Other Hella Numbers 4RD933332-20,
4RD-933332-207
933332-207
933332207
87421

87421B,
933332201,
960388507
Can Use 933332201






Hella Relay 12 Volt 4RA93791-06 Special Relay.
933791061
Your Cost $16.25


Hella 40 Amp 12 VOLT DC
SPDT Power Relay.
This 5 Prong Hella Relay.
Features 2 - # 87 Common Circuit.
40A NO Circuit
Continuous Duty
May Replace Other Hella Numbers
003510151, 4RA933791-06
87118, H4151021
Can Replace 0 332 019 150 Bosch 0332019150

Click Here
For More Information

Hella Relay 12 Volt 4RD931410-05-08 , 4RD931410-087, 87417 HL87417 Special Small Pin Configuration .
H41410081
Your Cost $17.75


Hella 40 Amp 12 VOLT DC
SPDT Power Relay.
This 5 Prong Hella Relay has many uses.
Features a NO & NC circuit.
40A NO Circuit / 20A NC Circuit
Continuous Duty W/Resistor
680 Ohms
May Replace Other Hella Numbers
4RD931410-08
4RD931410-05-08
4RD 931 410-5/-08

4RD931410-087, 87417 HL87417
87417,
931410087
ISO280 Small Pin Configuration

H84708001 Hella Relay 12 Volt ISO280 Special Small Pin Configuration Pigtail.
H84708001
ISO280 Pin Configuration
Weatherproof Skirted Socket
Your Cost $29.95

Hella Relay Wiring Harness For Weatherproof Hella Relays.
H84709001
Your Cost $28.75


Relay Wiring Harness for Hella Weatherproof Skirted Relays.
Has 5 = 12" Leads
(2) = 14-16ga.Coil Activating leads
(3) = 12ga. Battery & Load Leads
Replaces Hella 358114921
Hella Relay Wiring Kit For Weatherproof Hella Relays. Everything you need to make your own custom wiring harness.
H84709001K
Your Cost $18.75


Hella Relay Wiring Kit For Weatherproof Hella Relays. Everything you need to make your Own Custom Wiring Harness For Weatherproof Skirted Relays.
(2) = 14-16ga.Coil Activating Term.
(3) = 12ga. Battery & Load Term

John Deere Diode Relay 9 Pin 12 Volt RE39967, 8ES 931 452-00
H44452001
NLA

John Deere Diode Relay
9 Pin 12 Volt
John Deere RE39967
Hella 8ES 931 452-00
Use Base H84526001
John Deere Diode Relay 9 Pin Base For Relay RE39967, 8ES 931 452-00
H84526001K
Your Cost $12.50
With Terminals

For More Information
Click Here

Hella H41524021 Hella 20 Amp Mirco SPDT Relay.
965453041
Old # H41524021
Your Cost $12.75

Hella 20 Amp 12 VOLT DC
Power Relay.
Features a NO & NC circuit.
20A NO Circuit / 10A NC Circuit
Continuous Duty W/Resistor
May Replace Other Hella Numbers 4RD931524-02, 87416

Replaces Cole Hersee MC250012RN

5 Pin Micro Relay Housing Pigtail
MRHPT
Your Cost $6.75
Micro Relay Housing Pigtail
With 5 16 ga. Leads
(3) 4.8mm 3/16" Terminals
(2) 6.3mm 1/4" Terminals
For Bosch 4 & 5 Terminal
Micro Relay & Other Brand of Micro Relays
Back To Top Of Page
Hella TIme Delay Relays Hella 12 & 24 Volt
996152131 Hella Amp 12 Volt 10 Amp SPDT Time Delay Relay Adjustable from 0-900 Seconds
996152131
Your Cost
$88.50
12 Volt Hella Time Delay Relay
Hella 996152131 12 Volt
5HE 996 152-131
5HE.996.152-131
996 152 131
SPDT 5 Terminal
Continuous Duty 10 Amp Max
Adjustable from 0-900 Seconds

Delay on Release
Comes with Snap in Mounting Tab.
Has Normally Closed & Normally Open Circuit
Great for all kind's of electrical projects.
Click Here For More Information
For Relay With 5 Terminals & Housing Order 996152131K

996152141 24 Volt Hella 10 Amp SPDT Time Delay Relay Adjustable from 0-900 Seconds
996152141
Your Cost
$90.50
24 Volt Hella Time Delay Relay
Hella 996152141 24 Volt
5HE 996 152-141
5HE.996.152-141
996 152 141
SPDT 5 Terminal
Continuous Duty 10 Amp Max
Adjustable from 0-900 Seconds

Delay on Release
Comes with Snap in Mounting Tab.
Has Normally Closed & Normally Open Circuit
Great for all kind's of electrical projects.
Click Here For More Information
For Relay With 5
Terminals & Housing Order 996152141K
996152151 Hella Amp 12 Volt 10 Amp SPDT Time Delay Relay Adjustable from 0-900 Seconds
996152151
Your Cost
$85.50
12 Volt Hella Time Delay Relay
Hella 996152151 12 Volt
996 152 151
SPDT 5 Terminal
Continuous Duty 10 Amp Max
Adjustable from 0-900 Seconds

Delay on Operate
Comes with Snap in Mounting Tab.
Has Normally Closed & Normally Open Circuit
Great for all kind's of electrical projects.
Click Here For More Information
For Relay With 5 Terminals & Housing Order 996152151K
996152161 24 Volt Hella 10 Amp SPDT Time Delay Relay Adjustable from 0-900 Seconds
996152161
Your Cost
$90.50
24 Volt Hella Time Delay Relay
Hella 996152161 24 Volt
996 152 161
SPDT 5 Terminal
Continuous Duty 10 Amp Max
Adjustable from 0-900 Seconds

Delay on Operate
Comes with Snap in Mounting Tab.
Has Normally Closed & Normally Open Circuit
Great for all kind's of electrical projects.
Click Here For More Information
For Relay With 5 Terminals & Housing Order 996152161K


Song Chuan 12 Volt SPST & SPDT Relays
Click Here For Relay Information
Song Chuan Relay 301-1A-C-R1-U03-12VDC SPDT ISO280 with Resistor
301-1A-C-R1-U03-12VDC
Your Cost

$10.50

Song Chuan Relay
12 Volt Micro Relay Continuous Duty
SPST 35A
301-1A-C-R1-U03-12VDC
ISO 280 with Resistor

4 = 2.8mm Terminals

Click Here For Relay Information
301-1C-C-D1-24VDC SONG CHUAN 5 Prong SPDT 30/20 Amp 24 VOLT Relay

301-1C-C-D1-24VDC

Your Cost

$10.50

Song Chuan Relay
24 Volt Micro Relay
Continuous Duty

SPDT 15A / 10A
301-1C-C-D1-24VDC
3011CC-D1-24VDC
ISO280 with Diode

5 = 2.8mm Terminals

Click Here For Relay Information
301-1C-C-R1-U01-12VDC SONG CHUAN 5 Prong SPDT 50/30 Amp Relay

301-1C-C-R1-U01-12VDC

Your Cost

$12.50

Song Chuan Relay
12 Volt Micro Relay Continuous Duty
SPDT 35A / 15A
301-1C-C-R1-U01-12VDC
3011CCR1U0112VDC
ISO280 with Resistor
5 = 2.8mm Terminals

Will Replace OMRON G8V-RH-1C7T-R-DC12
G8VRH1C7TRDC12


Click Here For Relay Information
Song Chuan Relay 303-1AH-C-U01-12VDC SPDT ISO280 with Resistor
303-1AH-CR1-U01-12VDC

Your Cost
$10.50

Song Chuan Relay
12 Volt Micro Relay
Continuous Duty With Resistor

SPST 20A
303-1AH-C-R1-U01-12VDC
3031AHCR1U112VDC
ISO 280 with Resistor

4 = 2.8mm Terminals

Click Here For Relay Information
871-1C-C-D1-12VDC SPDT 35A NO / 20A NC with Diode

871-1C-C-D1-12VDC

Your Cost
$12.50

Song Chuan Micro Relay
12 V 35A NO / 20A NC
Continuous Duty

SPDT With Diode
(2 ) .250"&
( 3 ) .187" Terminals. Please Specify if you need 10 ga terminals for the .250 blade term

Click Here For Relay Information

896-1CH-C-R1-U03 SONG CHUAN 5 Prong SPDT 50/30 Amp Relay
896H-1CH-C-R1-U03-12VDC

Your Cost

$12.75


50 Amp 12 VOLT DC
Power Relay.
This SONG CHUAN 5 Prong Relay has many uses.
Features a
NO 50A
NC 30 A
With Resistor
Sealed Base
Continuous Duty
# 85 .250
# 86 .250
# 30 .250"
# 87 .250
# 87a .250
May Replace Bosch
0 332 209 137
0332209137

896H1CHCR1U312VD
896H-1CH-C-R1-U03-12VDC
896H1CH-C-R1 U03

Click Here For Relay Information

896H-1CH-D1SW-001 12VDC 12V 50/30 AMP RELAY SKRITED WATERPROOF
896H-1CH-D1SW-001
12VDC
Your Cost
$16.50

50 Amp 12 VOLT DC SPDT
Power Relay.
This SONG CHUAN 5 Prong Relay has many uses.
Features a
NO 50A
NC 30 A
With Diode
Continuous Duty
# 85 .250
# 86 .250
# 30 .250"
# 87 .250
# 87a .250
896H-1CH-D1SW-001 12VDC
896H1CHD1SW-001 12VDC


Click Here For Relay Information
Song Chuan Relay 898H-1AH-C-R1-U04-12VDC SPST ISO280 with Resistor
898H-1AH-C-R1-U04-12VDC

Your Cost
$16.50

Song Chuan Relay
12 Volt Micro Relay
Continuous Duty

SPST 50A
Coil Resistance 90 OHM
898H1ACR1U041VDC
ISO 280 with Resistor

4 = 2.8mm Terminals

Click Here For Relay Information
Song Chuan Relay 898H-1CH-R1-U03-12VDC SPDT ISO280 with Resistor
898H-1CH-C-R1-U03-12VDC

Your Cost
$14.50
Soon to be NLA

Song Chuan Relay
12 Volt Micro Relay
Continuous Duty

SPDT 50A / 30A
Coil Resistance 90 OHM
898H1ACR1U031VDC
ISO 280 with Resistor

5 = 2.8mm Terminals

Back To Top Of Page
Stancor / White Rodgers
Relays Continuous Duty & Intermittent Duty Relays 12 Volt,24 Volt & 36 Volt

Click Here View White Rodgers / STANCOR Production Numbers Cross Reference

Click her for more Information
70-901 Special Application 6 Volt DC Continuous Duty Relay

70-901
Your Cost
$49.50
6 Volt 80 Amp
Coil Type: Insulated Coil Ground
Coil Volts DC: 6V DC
Contact Form: SPNO
Duty Cycle: 80 Amp Continuous
300 Amp Inrush

Coil Termination: #10-32
Contact Termination: 5/16-24
Contacts : Copper
White Rodgers Numbers
70-180224-5A, 70-901S1
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference
Click her for more Information
Special Application 12 Volt DC Continuous Duty Relay

70-902
Your Cost
$45.50
12 Volt 80 Amp
Coil Type: Insulated Coil Ground
Coil Volts DC: 12 DC
Contact Form: SPNO
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
Contacts : Copper
White Rodgers Numbers
70-111224-5 / 70-111224-5A
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference
Click her for more Information
24 Volt Special Application 24 Volt DC Continuous Duty Relay.

70-903
Your Cost
$42.50
24 Volt 50 Amps
Coil Type: Insulated Coil Ground
Coil Volts DC: 24 DC
Contact Form: SPNO
Duty Cycle: Continuous Duty
Coil Termination: #10-32
Contact Termination: 5/16-24
Contacts : Copper
White Rodgers Numbers
WR 70-111224-5 / WR 70-111224-5A
70-117224-5A
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click her for more Information
Special Application 36 Volt DC Continuous Duty Relay

70-904
Your Cost
$38.50
36 Volt
Amps:50
Inrush 200 Amp

Coil Type: Insulated Coil Ground
Coil Volts DC: 36 Volt DC
Contact Form: SPNO
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
Contacts : Silver
White Rodgers Numbers
70-120224, 70-120224-5A, 70-904S1
Johnson Electric 5118540, SO51185
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference
Click her for more Information
Special Application 12 Volt DC Continuous Duty Relay

70-906
Your Cost
$85.50
12 Volt Special Applications
Amps:80
Coil Type: Insulated Coil Ground
Coil Volts DC: 12 DC
Contact Form: SPNO
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
Contacts : Silver
White Rodgers Numbers
70-111221-5 / 70-111221-5A
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click her for more Information
Special Application 12 Volt DC Continuous Duty SPDT Relay

70-922
NLA
May be able to Use
Ametek 15-323
12 Volt Special Applications
Amps:80 Amp NO / 60 Amp NC
Coil Type: Insulated Coil Ground
Coil Volts DC: 12 DC
Contact Form: SPDT
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
Contacts : Silver /Copper
White Rodgers Numbers
WR 70-311224-5 / 70-311224-5A
70-311224-5 / 70-311224-5A
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click On Relay
For More Information

12 Volt 100 Amp Special Applications  Relays.
120-901
Your Cost
$48.50
12 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Insulated Coil Ground
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
White Rodgers Numbers
120-105711 / 120-105751-6 , 6C017
May be used to replace 120-106131
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.


Click On Relay
For More Information

120-902 15 Volt 100 Amp Special Applications  Relays.
120-902
Your Cost
$48.50
15 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Insulated Coil Ground
Coil Volts DC: 15 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
White Rodgers:
120-108751, 120-108751-6, 120-902S1
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.


Click On Relay
For More Information

124-904 24 Volt 100 Amp Special Applications  Relays.
120-904
Your Cost
$69.50
24 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Insulated Coil Ground
Coil Volts DC: 24V DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
White Rodgers Numbers
120-114751-2
, 120-114751-6
1201147515, 120-114751-5 , 120-904S1
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.


Click On Relay
For More Information

124-905 36 Volt 100 Amp Special Applications  Relays.
120-905
Your Cost
$63.50
36 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Insulated Coil Ground
Coil Volts DC: 36V DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
White Rodgers Numbers

Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.

Click On Relay
For More Information

12 Volt 100 Amp Continuous Duty  Relays.
120-907
Your Cost
$48.50
12 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Insulated Coil Ground
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.

Coil Termination: #10-32

Contact Termination: 5/16-24
White Rodgers Numbers
120-105112, 120-105115-2
120-105752 120-105752-6

Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.

Click On Relay
For More Information

15 Special Applications  Relays.
120-908
Your Cost
$47.50
15 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Insulated Coil Ground
Coil Volts DC: 15 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.

Coil Termination: #10-32

Contact Termination: 5/16-24
White Rodgers Numbers
120-108752, 120-108752-6
May Replace
White Rodgers 120-107712
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.

Click On Relay
For More Information

120-910 12 Volt 100 Amp Continuous Duty Relay.
120-910

Your Cost
$74.50

12 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Coil Grounded
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle:
Continuous Duty.
Coil Termination: #10-32
Contact Termination: 5/16-24
White Rodgers Numbers
120-120-114752-6
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.

Click On Relay
For More Information

120-912 12 Volt 100 Amp Intermittent Duty Relay.
120-912

Your Cost
$34.50

12 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Coil Grounded
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Intermittent Duty.
Coil Termination: #10-32
Contact Termination: 5/16-24
White Rodgers Numbers
120-106762, 120-106762-6
6C019 / 6C-019
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.

Click On Relay
For More Information

120-913 12 Volt 100 Amp Relay 3 -Terminal.
120-913
120-105851

Your Cost
$43.50

12 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Coil Grounded
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.
Coil Termination: (1) #10-32
Contact Termination: (2) 5/16-24
White Rodgers Numbers
120-105211, 120-105851,
120-105851S1 120-913
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.

Click On Relay
For More Information

120-943 12 Volt 100 Amp Relay.
120-943

Your Cost
$79.90

12 Volt Special Applications
Amps: 100
400 Amps Inrush
Coil Type: Coil Grounded
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Const.
Coil Termination: #10-32
Contact Termination: 5/16-24
White Rodgers Numbers
120-105452-6 May Replace
White Rodgers 120-105212

120-943S1
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference

Click Here to View The 120 Series Part Numbering System Data.

Click On Relay
For More Information

Special Applications Relays.
124-902
Your Cost
$66.50

12 Volt Special Applications
Equipment Electrical Power Supply Relays
Ambulance Electrical Control Panels
Amps: 100
Amps: 400 Inrush
Number of Terminals: 4
Coil Type: Isolated
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Continuous

White Rodgers Numbers
124-105111, 124-105111-3
, 6C020
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


Click On Relay
For More Information

24 Volt 100 Amp Special Applications Relays.
124-903
Your Cost
$75.80

24 Volt Special Applications
Equipment Electrical Power Supply Relays
Ambulance Electrical Control Panels
Amps: 100
Amps: 400 Inrush
Number of Terminals: 4
Coil Type: Isolated
Coil Volts DC: 24 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Continuous

White Rodgers Numbers
124-114111, 124-114111-3,
124-114111-5, 6C021

Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


Click On Relay
For More Information

Special Applications Relays.
124-906
Your Cost
$81.80

12 Volt Special Applications
Equipment Electrical Power Supply Relays
Ambulance Electrical Control Panels
Amps: 100
Amps: 400 Inrush
Number of Terminals: 3
Coil Type: Grounded Case
Coil Volts DC: 12 DC
Contact Form: SPNO
Contact Material : Silver Alloy
Duty Cycle: Continuous

White Rodgers Numbers
124-105211
124-105211-3
124-105211-5

5120740, SO51207
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


Click On Relay
For More Information

12 Volt Forward & Reverse Systems ,Winches used in some Auto Crane Applications.
124-910
Your Cost
$90.75

12 Volt Special Applications
Forward & Reverse Systems ,Winches used in some Auto Crane Applications.
Normally Open & Normally Closed Circuit
Amps: 100
Amps: 400 Inrush
Number of Terminals: 6
Coil Type: Isolated
Coil Volts DC: 12
Contact Form: SPDT DC
Contact Material : Silver Alloy
Duty Cycle: Continuous
White Rodgers Numbers
124-305111, 124-305111-3
, 6C023
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


Click On Relay
For More Information

24 Volt Forward & Reverse Systems ,Winches used in some Auto Crane Applications.
124-911
Your Cost
$114.75


24 Volt Single Pole, Double Throw
Isolated Coil,
Silver Alloy Contacts,
200A Normally Open,
600A Open Inrush,
50A Normally Closed,
100A Closed Inrush,
Number of Terminals: 6
Special Applications Forward & Reverse Systems
Winches used in some Auto Crane Applications.
White Rodgers Numbers Reference Numbers
124-314111-3
124-314111-5

Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.





Click On Relay
For More Information

EXTRA HEAVY DUTY ELECTRICAL LOADS USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS.
586-902
Your Cost
$113.50





586-903 15 Volt Coil, EXTRA HEAVY DUTY ELECTRICAL LOADS USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS.


586-903
Your Cost
$123.50

586-108111
586-108111-3


12 Volt Special Applications, EXTRA HEAVY DUTY ELECTRICAL LOADS USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS
MARINE USES..
Amps: 200
Inrush: 600
Coil Type: Isolated
Coil Volts DC: 12 DC
Contact Form: SPNO
Number of Terminals: 4
Contact Material: Silver
Duty Cycle: Continuous
White Rodgers Numbers
586-105111 AND 586-105111-3

OEM 712 Yamaha: JF2-H1950-00
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


586 Series Numbering Identifying Info



586-903
15 Volt Coil
Amps: 200
Inrush: 600
Coil Type: Isolated
Coil Volts DC: 15 DC
Contact Form: SPNO
Number of Terminals: 4
Contact Material: Silver
Duty Cycle: Continuous
White Rodgers Numbers
586-108111 AND 586-108111-3


586 Series Numbering Identifying Info


Click On Relay
For More Information

EXTRA HEAVY DUTY ELECTRICAL LOADS USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS.
586-905
Your Cost
$107.50





Click On Relay
For More Information

36 VOLT EXTRA HEAVY DUTY ELECTRICAL LOADS USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS.
586-906
Your Cost
$113.50


24 Volt Special Applications, EXTRA HEAVY DUTY ELECTRICAL LOADS USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS
MARINE USES..
Amps: 200
Inrush: 600
Coil Type: Isolated
Coil Volts DC: 24 DC
Contact Form: SPNO
Number of Terminals: 4
Contact Material: Silver
Duty Cycle: Continuous
White Rodgers Numbers
586-114111 AND 586-114111-3 , 6C025
May replace Cummins 3050692

586-114112-6A, 5861141126A
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.



586-906
36 Volt Special Applications,
ELECTRICAL LOADS USED IN MANY INDUSTRIAL
& MARINE APPLICATIO AERIAL LIFTS & SCISSOR LIFTS
AND
MARINE APPLICATION.
Amps: 200
Inrush: 600
Coil Type: Isolated
Coil Volts DC: 36 DC
Contact Form: SPNO
Number of Terminals: 4
Contact Material: Silver
Duty Cycle: Continuous
White Rodgers Numbers
586-117111 AND 586-117111-3 , 6C026
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


586 Series Numbering Identifying Info

Click On Relay
For More Information

48 VOLT EXTRA HEAVY DUTY ELECTRICAL LOADS USED IN MANY EMERGENCY VEHICLES APPLICATIONS LIKE,AMBULANCES,FIRE TRUCKS.
586-907
586-120111
Your Cost
$117.50

48 Volt Special Applications,
ELECTRICAL LOADS USED IN MANY INDUSTRIAL
& MARINE APPLICATIO AERIAL LIFTS & SCISSOR LIFTS
AND
MARINE APPLICATION.
Amps: 200
Inrush: 600
Coil Type: Isolated
Coil Volts DC: 48 DC
Contact Form: SPNO
Number of Terminals: 4
Contact Material: Silver
Duty Cycle: Continuous
White Rodgers Numbers
586-120111 AND 586-120111-3
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


586 Series Numbering Identifying Info





Click On Relay
For More Information

12 Volt Special Applications  Relays.
586-911
Your Cost
$161.75


12 Volt Special Applications.
For Forward & Reverse Systems.
Normally Open & Normally Closed Circuit

Amps: 200
Inrush: 600
Coil Type: Isolated
Coil Volts DC: 12 DC
Contact Form: SPDT
Number of Terminals: 6
Contact Material: Silver
Duty Cycle: Continuous
White Rodgers Numbers
586-305111 AND 586-305111-3
Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


586 Series Numbering Identifying Info


Click On Relay
For More Information

24 Volt Special Applications  Relays.
586-914
586-314111
Your Cost
$159.60


2
4 Volt Special Applications.
For Forward & Reverse Systems.
Normally Open & Normally Closed Circuit

Amps: 200
Inrush: 600
Coil Type: Isolated
Coil Volts DC: 24 DC
Contact Form: SPDT
Number of Terminals: 6
Contact Material: Silver
Duty Cycle: Continuous
White Rodgers Numbers
References:
Johnson Electric 5122940, SO51229
White Rodgers/ Stancor
586-314111, 586-314111-3

586-314111-5, 5122940, SO51229

Click Here View
White Rodgers / STANCOR
Production Numbers
Cross Reference.


586 Series Numbering Identifying Info

1N5402 3 Amp 200 Volt Diode
1N5402
3 Amp 200 Volt Diode
Can Be Connected Across
The Relay Activating Terminals
To Dump Discharge Voltage
Spikes When Relay is Turned Off
Your
Cost
$0.65
1N5402 3 Amp 1200 Volt Diode
1N5408
3 Amp 1200 Volt Diode
Can Be Connected Across
The Relay Activating Terminals
To Dump Discharge Voltage
Spikes When Relay is Turned Off

Your Cost
$0.65

PX6A07 6 Amp 1000 Volt Diode
PX6A07
6 Amp 1000 Volt Diode
Can Be Connected Across
The Relay Activating Terminals
To Dump Discharge Voltage
Spikes When Relay is Turned Off

Your Cost
$1.75
Back To Top Of Page
Trombetta Relays
Continuous Duty & Intermittent Duty Relays 12 Volt,24 Volt

Click Here or On Relay
For More Information
12 Volt 200A Carry Rating

404-1231-032
Your Cost
$121.50
12 Volt 200 Amp Continuous Duty
This Contactor can handle environments with extreme temperatures, moisture and high vibration.
It is designed to carry currents as low as 350 milliamps and as high as 200 amps. The Defender has built in Transient Voltage Suppression (TVS) which protects other sensitive components in your system. Defender Series
Cast Housing, 200A Carry Rating
Silver Contacts, Sealed
(2) 5/16-24 studs
Deutsch 2-pin connector (DT06-25)
4041231032
404 1231 032
Click Here or On Relay
For More Information

24 Volt 200A Carry Rating
404-2431-032
Your Cost
$120.50
24 Volt 200 Amp Continuous Duty
This Contactor can handle environments with extreme temperatures, moisture and high vibration.
It is designed to carry currents as low as 350 milliamps and as high as 200 amps. The Defender has built in Transient Voltage Suppression (TVS) which protects other sensitive components in your system. Defender Series
Cast Housing, 200A Carry Rating
Silver Contacts, Sealed
(2) 5/16-24 studs
Deutsch 2-pin connector (DT06-25)

Trombetta 634-1241-212-02 12 Volt 3 Terminal Starter Relay.
634-1241-212-02
Your Cost
$49.70

Trombetta
12 Volts 3 Terminal
Intermittent Duty Relay
Insulated Case
Plastic Housing
Flat 90 (F90) Bracket
2 = 5/16"-24 Copper Contacts.
1 = #10-32 Coil Terminals
Hydraulic, RV, Grid Heater & Lawn and Garden Applications
Click Here For
Trombetta Relay
Information Guide


Trombetta 634-1261-212 12 Volt 4 Terminal Starter Relay.
634-1261-212
Your Cost
$41.50

Trombetta
12 Volts 3 Terminal
Intermittent Duty Relay
Insulated Case
Plastic Housing
Curved Bracket 2.22in Radius (C222) Sealed
2 = 5/16"-24 Copper Contacts.
1 = #10-32 Coil Terminals
150A Carry, 800A Inrush,
25% Duty Cycle

Click Here For
Trombetta Relay
Information Guide



Trombetta 684-1211-012 12 Volt 4 Terminal Starter Relay.
684-1211-012
Your Cost
$45.50

Trombetta
12 Volts 4 Terminal
Continuous Duty Relay
Insulated Case
Plastic Housing
Curved Bracket 2.22in Radius (C222) Sealed Case
2 = 5/16"-24 Copper Contacts.
2 = #10-32 Coil Terminals
150A Carry, 800A Inrush,
12V CONTINUOUS DUTY 250A / 800A INRUSH
Click Here For
Trombetta Relay
Information Guide

Trombetta 684-1211-212 12 Volt 4 Terminal Starter Relay.
684-1211-212
Your Cost
$41.50

Trombetta
12 Volts 4 Terminal
Intermittent Duty Relay
Insulated Case
Plastic Housing
Curved Bracket 2.22in Radius (C222) Sealed Case
2 = 5/16"-24 Copper Contacts.
2 = #10-32 Coil Terminals
150A Carry, 800A Inrush,
25% Duty Cycle

Click Here For
Trombetta Relay
Information Guide
684-1221-012 Continuous Duty Relay 150A 800 Amp Inrush
684-1221-012
Your Cost
$66.75

Trombetta
12 Volts 4 Terminal
Continuous Duty Relay
Insulated Case
Plastic Housing
Flat Bracket, Sealed
2 = 5/16"-24 Copper Contacts.
2 = #10-32 Coil Terminals
150A Carry, 800A Inrush,
100% Duty Cycle

Click Here For
Trombetta Relay
Information Guide


684-1221-212 Intermittent Duty Relay 150A 800 Amp Inrush
684-1221-212
Your Cost
$42.75


Trombetta
12 Volts 4 Terminal
Intermittent Duty Relay
Insulated Case
Plastic Housing
Flat Bracket, Sealed
2 = 5/16"-24 Copper Contacts.
2 = #10-32 Coil Terminals
150A Carry, 800A Inrush
,25% Duty Cycle

Click Here For
Trombetta Relay
Information Guide


Trombette 684-1251-012-02 12 Volt Continuous Duty Relay
684-1251-012-02
Your Cost
$42.50

Trombetta
12 Volts
4 Terminal
Continuous Duty Motor Relay Insulated Case
Plastic Housing
5/16"-24 Copper Contacts.
Flat L Bracket
150A Carry, 800A Inrush,
100 % Duty Cycle

:Click Here For
Trombetta Relay
Information Guide




Trombette 684-1251-212- 12 Volt Intermittent Duty Relay
684-1251-212
Your Cost
$42.50

Trombetta
12 Volts
4 Terminal
Intermittent Duty Relay
Insulated Case
Plastic Housing
5/16"-24 Copper Contacts.
Flat L Bracket
150A Carry, 800A Inrush,
25 % Duty Cycle

:Click Here For
Trombetta Relay
Information Guide

Trombetta 684-1261-212 12 Volt 4 Terminal Starter Relay.
684-1261-212
Your Cost
$40.50

Trombetta
12 Volts
4 Terminal
Intermittent Duty Motor Relay
Insulated Case
Plastic Housing
5/16"-24 Copper Contacts.
Bracket Curved 2.22in Radius (C222)
150A Carry, 800A Inrush,25% Duty Cycle
References:
Replaces Trombetta 684-1251-212
Can Replace 3 Terminal Relay
634-1261-212 Just Add Ground Wire
Click Here For
Trombetta Relay
Information Guide

Trombetta 24 Volt Relay 684-2461-212
684-2461-212
Your Cost
$44.50

Trombetta
24 Volts
4 Terminal
Intermittent Duty Motor Relay
Insulated Case
Plastic Housing
5/16"-24 Copper Contacts.
Bracket Curved 2.22in Radius (C222)
150A Carry, 800A Inrush,25% Duty Cycle
Click Here For
Trombetta Relay
Information Guide


Trombetta 812-1211-211 12 Volt 3 Terminal Starter Relay
812-1211-211
Your Cost
$17.50


Trombetta
12 Volts
3 Terminal
Intermittent Duty Starter Relay
Grounded Case
Plastic Housing
1/4-20 Copper Contacts.
L Bracket.
Dust & Liquid Resistant
Application:
ATV, Utility Vehicle, Snowmobile, Golf Cart Lawn and Garden Equipment.
Replaces these old Numbers
812-1201-211-06
93245-1, 93245-2WR

Click Here For
Trombetta Relay
Information Guide


Trombetta 852-1251-210 12 Volt 3 Terminal Starter Relay
852-1251-210
Your Cost
$18.50


Trombetta
12 Volts
3 Terminal
Intermittent Duty Starter Relay
Grounded Case
Plastic Housing
1/4-20 Copper Contacts.
Universal Bracket L Bracket.
Dust & Liquid Resistant
Application:
ATV, Utility Vehicle, Snowmobile, Golf Cart, & Lawn and Garden Equipment

Click Here For
Trombetta Relay
Information Guide

12 Volts 4 Terminal Intermittent Duty Relay
892-1221-210
Your Cost
$18.50

Trombetta, Toro
12 Volts 4 Terminal
Intermittent Duty Relay
Horizontal Mounting Bracket
200 A With 300A Inrush,
Insulated Case
5/16" Copper Contacts.
8-32 Threaded with 1/4" Male Blade Spades.
References Trombetta

884-1221-210-02, 892-1221-210,
894-1221-210, 94285
Click Here For
Trombetta Relay
Information Guide


12 Volt Trombetta Replaces: 97240, 97240-2, 97240-3, 934-1243-610-15 .
934-1215-010-16
Your Cost
$66.75


Trombetta
12 Volts 3 Terminal
Continuous Duty Relay
Grounded Case
Metal Housing
5/16" Copper Contacts.
Curved Slot Bracket.
Replaces: 97240, 97240-2, 97240-3
934-1243-610-15

Trombetta Metal
Relay Information Guide

12 Volt SPDT 970-1215-210-24 Trombetta
970-1215-210-24
Your Cost
$103.50

12 Volt DC SPDT TROMBETTA RELAY
"Forward & Reverse Systems like Winches ,Ramsey & Warn Winches Control Box's,Golf Carts
(2 Required)
and much more"
Insulated Ground Circuit
Normally Open & Normally Closed Circuits
Circuitry SPDT
Contacts : Copper
Housing : plated steel
Voltage Rating 12V DC
Terminals copper; 10-32 thread
and 5/16"-24 thread.
INTERMITTENT DUTY 300 AMPS
5
00AMP SURGE

12 Volt Trombetta Replaces: 98226-9, 974-1215-011-09.
974-1215-011-09
Your Cost
$59.50


Trombetta
12 Volts 4 Terminal
Continuous Duty Relay
Insulated Case
Metal Housing
Dust & Liquid Resistant
5/16" Copper Contacts.
Flat Base Slot Bracket.
Replaces:974-1215-011, 98226-9,
98226-WR 98226WR

Trombetta Metal
Relay Information Guide

12 Volt Trombetta Replaces:97220, 97220-1,   974-1215-610
974-1215-610
Your Cost
$82.58


Trombetta
12 Volts 4 Terminal
Intermittent Duty Relay
Insulated Case
Metal Housing
5/16" Copper Contacts.
Flat Base Slot Bracket.
Replaces:
974-1215-610-09, 974-1215-610-16

98220, 98220-4, 98220-6
Trombetta Metal
Relay Information Guide

12 Volt Trombetta  974-1235-211-12
974-1235-211-12
Your Cost
$68.50


Trombetta
12 Volts 4 Terminal
300A Intermittent Duty Relay
Insulated Case
Metal Housing
5/16" Copper Contacts.
Flat Base F180 Bracket.
Replaces:
974 1235 211 12

Trombetta Metal
Relay Information Guide

Trombetta 974-2415-010-09  24 Volt 4 Terminal  Relay
974-2415-010-09
Your Cost
$68.50


Trombetta
24 Volts 4 Terminal
Continuous Duty Relay
Insulated Case
Metal Housing
5/16" Copper Contacts.
Flat Slot Bracket.
Replaces 974-2415-010

Trombetta Metal
Relay Information Guide

TYCO 12 Volt to 48 Volt Relays & Specialty Relays
Click On Relay
For Drawing
Click Here for More Information on the LEV200 Series Contactor 12 volt 500 Amp Continuous Duty.
LEV200A4NAA
1618387-1
Your Cost
$197.50
12 Volt Special Applications Contactor
TE Connectivity / Kilovac Brand
KILOVAC CONTACTOR
Normally Open

Amps: 500
Inrush: 1200
Coil Type: Isolated
Coil Volts DC: 12 DC SPST
Contact Form: SPST
Number of Terminals: 4
Mechanical Life Cycles 100,000
Flange Mount
Contact Material: Copper
Duty Cycle: Continuous
Click On Relay
For Drawing
12 Volt 500 Amp Contiouous Duty Relay
LEV200A4NAF
1618387-5
Your Cost
$209.00
12 Volt Special Applications Contactor
TE Connectivity / Kilovac Brand
KILOVAC CONTACTOR
Normally Open

Amps: 500
Inrush: 1200
Coil Type: Isolated
Coil Volts DC: 12 DC SPST
Contact Form: SPST
Number of Terminals: 4
Mechanical Life Cycles 100,000
Side Mount
Contact Material: Copper
Duty Cycle: Continuous

Click On Relay
For Drawing
Click Here for More Information on the LEV200 Series Contactor 24 volt 500 Amp Continuous Duty.

LEV200A5NAA
4-1618388-6
Your Cost
$197.50

24 Volt Special Applications Contactor
TE Connectivity / Kilovac Brand
KILOVAC CONTACTOR
Normally Open

Amps: 500
Inrush: 1200
Coil Type: Isolated
Coil Volts DC: 24 DC SPST
Contact Form: SPST
Number of Terminals: 4
Mechanical Life Cycles 100,000
Flange Mount
Contact Material: Copper
Duty Cycle: Continuous
Click On Relay
For Drawing
Click Here for More Information on the LEV200 Series Contactor 24 volt 500 Amp Continuous Duty.
LEV200A5NAF
5-1618387-7
Your Cost
$198.50
24 Volt Special Applications Contactor
TE Connectivity / Kilovac Brand
KILOVAC CONTACTOR
Normally Open

Amps: 500
Inrush: 1200
Coil Type: Isolated
Coil Volts DC: 24 DC SPST
Contact Form: SPST
Number of Terminals: 4
Mechanical Life Cycles 100,000
Flange Mount
Contact Material: Copper
Duty Cycle: Continuous
Click Here Or on Relay
For More Information

TYCO Relay 130 Amp 12 VOLT DC Continuous Duty

V23132-A2001-A200
1393315-2
Your Cost
$68.50

Tyco Continuous Duty Relay
130 Amp 12 VOLT DC
4 Prong SPST Heavy Duty Relay
This Relay has many Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Comes With (2) Activating Terminals & Sealed Terminal Housing.
V23132A2001A200
TYCO Number 1393315-2

Click Here Or on Relay
For More Information

TYCO Relay 130 Amp 12 VOLT DC Continuous Duty

V23132-A2001-B200
1415010-1
Your Cost
$85.50

Tyco Continuous Duty Relay
130 Amp 12 VOLT DC
4 Prong SPST Heavy Duty Relay
This Relay has many Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Comes With (2) Activating Terminals & Sealed Terminal Housing.
V23132A2001B200
TYCO Number 1416010-1


V23232-D0001-X001
1904000-1
Your Cost
$54.50
Will Replace Bosch
0 332 002 150 & 0 332 002 168





75 Amp 12 VOLT DC Tyco
Continuous Duty
This 4 Prong Heavy Duty Relay has many
Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With
(2) Activating Terminals & Housing.

Bosch 0332002150 0-332-002-150
Can Replace Lucas 33RA,
SRB600 Black, SRB630, Blue SRB631, Green, Series Relays
I/D Intermittent Duty 12 Volt 60 Amp Tyco V23232 D0001 X001
V23232D0001X001
V23232-D0001-X001 1904000-1
0332002150 Bosch
0-332-002-150 Bosch
0 332 002 150 Bosch


V23232-E0003-X008
1904002-2
Your Cost
$54.50

Will Replace Bosch
0 332 002 250 & 0 332 002 258



50 Amp 24 VOLT DC Tyco
Continuous Duty
This 4 Prong Heavy Duty Relay has many
Automotive uses, it features a NO circuit.
Applications: May be used to power,Large Electric Cooling Fans, Driving Lights,Automotive Electrical Accessories.
Supplied With (2) Activating Terminals & Housing.
Can Replace Lucas
33RA SRB601 Red, 33RA SRB632 Blue Relay
0332002250 Bosch 24 Volt Relay
C/D Continuous Duty.
0332002258 0-332-002-258

Tyco V23232 E0002 X007
V23232E0002X007
V23232-E0002-X007
1904002-2


V23074-A1002-A403
3-1393292-8
Your Cost
$10.50



Tyco 20 Amp 12 VOLT DC
Power Relay.
Features a NO & NC circuit.
20A NO Circuit / 10A NC Circuit
Continuous Duty W/Resistor
V23074-A1002-A403

Click Here For More Information
TE Connectivity (TYCO) 48 Volt 30 Amp SPST-NO.
T9AP1D52-48-01
5-1419102-8

48 Volt 30 Amp
Your Cost
$14.50

48 Volt 30 Amp 277VAC SPST-NO
Continuous Duty Can be used
on DC Circuit Up to 12.5 amp DC max.
TE Connectivity (TYCO)
General Purpose Relay
Contact:Silver Cadmium Oxide
Flange Mount

Coil Resistance: 2.304k Ohms
Height: 27.94
Length: 50.29
Width: 27.43


Back To Top Of Page
Zettler Relays High Capacity Mini Relays



Click Here For More Information
Zetter 24 Volt 80 Amp SPST 4 Terminal Continuous Duty Relay.

70AR-24
Your Cost
$14.75




24 Volt 80 Amp
Zettler High Capacity Mini Relay
High Capacity Mini Relay
SPST 4 Prong
Cap Material = Plastic
4 Terminals:

# 85 .250
# 86 .250
# 30 .375"
# 87 .375
24 volts 80 amps
Continuous Duty.
NO Mtg Bracket.

Sealed
AZ980-1A-24DE

Click Here For More Information
Zetter 24 Volt 80 Amp SPST 4 Terminal Continuous Duty Relay.

70ARB-24
Your Cost
$14.75




24
Volt 80 Amp
Zettler High Capacity Mini Relay
High Capacity Mini Relay
SPST 4 Prong
Cap Material = Plastic
4 Terminals:

# 85 .250
# 86 .250
# 30 .375"
# 87 .375
24 volts 80 amps
Continuous Duty With Mtg Bracket
Unsealed

AZ979-1A-24DE
Can Replace Tyco Relays V23134J1053D642, VF7-41H11
Hella 003437097, 4RA00343709, H41437051

Click Here For More Information
Zetter 24 Volt 80 Amp SPDT Continuous Duty 5 prong Relay

70ARB24-DT
Your Cost
$14.75



24
Volt 80 Amp
Zettler High Capacity Mini Relay
High Capacity Mini Relay
SPDT 5 Prong
Cap Material = Plastic
5 Terminals:

# 85 .250
# 86 .250
# 30 .375"
# 87 .375
# 87a .375

24 volts 80 amps
Continuous Duty With Mtg Bracket
Unsealed

Can Be wired to be used for permanent magnet motors.
Such as Small Winches,
Small Hoist Any Small Reversible Permanent Magnet Motor.

AZ979-1C-24DE

70 Amp 24 VOLT DC Relay Kit
70ARK-24
Your Cost
$23.50

70 Amp 24
VOLT DC Relay Kit 70ARK-24
This 4 Prong Relay & Relay Housing With Terminals.
Will Accommodate the 4 prong 70 amp SPST relays.
Applications: May be used to power,larger Size Electric Cooling Fans, Driving Lights, Much more.
Relay With Mounting Tab .
70RHB With (4 ) Terminals.
Comes with( 2 ) .250" & ( 2 ) .375" Power Terminals
Can accommodate to 8 ga wire size.
Please Specify if you need 8 ga Terminals.


Click Here For More Information


AZ986-1C-24DC4R1
Your Cost
$14.50


Zetller 40 Amp 24 VOLT DC
SPDT Power Relay.
This 5 Prong
Features a NO & NC circuit.
40A NO Circuit / 20A NC Circuit
Weatherproof Skirt
Continuous Duty W/Resistor
2700 Ohm ½ w resistor
in parallel with 24 V coil

ISO280 Small Pin Configuration

H84708001 Hella Relay 12 Volt ISO280 Special Small Pin Configuration Pigtail.
H84708001
ISO280 Pin Configuration
Weatherproof Skirted Socket
Your Cost $24.50

Pump Motor Contactor's, Starter Relays & Specialty Relays

Click On Image
For More Information
10511414 12 Volt Solenoid Control Relay For Delco 39MT PLGR Starters, Mitsubishi

10511414
Your Cost
$42.50

12 Volt Delco Solenoid Control Relay
12 Volt Delco Remy
Intermittent Duty
4 Terminal
Delco 39MT PLGR Starters, Mitsubishi
Replaces Delco 10511368, 10511414
Used on Delco Starters 8200037, 8200091, 8200287, 8200289, 8200290, 8200291, 19011515, 19011516, 19011521, 19011530
10511368, 10516526, 10518028

Click On Relay
For More Information
10511415 24 Volt Solenoid Control Relay For Delco 39MT PLGR Starters, Mitsubishi 24 Volt Starters.

10511415
Your Cost
$42.50

24 Volt Delco Solenoid Control Relay
24 Volt Delco Remy
Intermittent Duty
4 Terminal
Delco 39MT 24 Volt PLGR Starters.

Mitsubishi 24 Volt PLGR Starters
Used On Delco Starters
19011522, 19011523, 19011524

Click On Image
For More Information

12 volt 3 Terminal Delco 38MT PLGR Starters 10512096, 10511370,10516525
10512096
Your Cost
$39.50

12 Volt Delco Solenoid Control Relay
12 Volt Delco Remy
Intermittent Duty
3 Terminal
Delco 38MT PLGR Starters
Replaces Delco 10511370, 10516525

Click On Image
For More Information
10515812 12 Volt Solenoid Control Relay For Delco 29MT PLGR Starters.

10515812
Your Cost
$41.50




12 Volt Solenoid Control Relay

12 Volt
Intermittent Duty
3 Terminal
Delco 29MT PLGR Starters
Replaces Delco 10515812
Used on Delco Starters 8200003, 8200103
ZM3407 , 12019
Delco Remy Starter Relay 1114532 12 Volt 3 Terminal
1114532
Your Cost
$51.50


12 Volts Delco Remy
3 Terminal
Insulated Ground Circuit
HD Intermittent Duty Starter Solenoid Relay
SPST
Copper Contacts
Metal Case
SAE Marine Grade
5/16-24 Load Terminals
8-32 Coil Terminals
Replaces Delco Remy 1114532
1114209, 1114233, 1114244, 1466, D927, D989

Delco Remy Starter Relay 1115615 / 1114533 24 Volt
1115615
Your Cost
$67.50


24 Volts Delco Remy
4 Terminal
Insulated Ground Circuit
.66-.79 Amp Coil Draw
40 Amp Rated
HD Intermittent Duty Starter Solenoid Relay
SPST
Copper Contacts
Metal Case
SAE Marine Grade
5/16-24 Load Terminals
10-32 Coil Terminals
Replaces Delco Remy 1114533
May Use Cole Hersee 24063 / 24144 / 15-141
Delco Remy Starter Relay 1115616 / 1114535 12 Volt
1115616
Your Cost
$69.50

12 Volts Delco Remy
4 Terminal
Insulated Ground Circuit
2.4 to 2.6 Amp Coil Draw
40 Amp Rated
HD Intermittent Duty Starter Solenoid Relay
SPST
Copper Contacts
Metal Case
SAE Marine Grade
5/16-24 Load Terminals
8-32 Coil Terminals
Replaces Delco Remy 1114535

ISKRA / Letrika/MAHLE 24 Volt Relay / Solenoid. 300A Intermitted Duty.
MX38
11.250.176

Your Cost
$185.00

ISKRA / Letrika/MAHLE
12 Volt Relay / Solenoid
300A Intermitted Duty.
Mounts on Pump Motors
(2) M10-1.5 Threaded Terminals
(2) 6.5mm Blade Terminals
11250176
ADR1302

ISKRA / Letrika/MAHLE 24 Volt Relay / Solenoid. 300A Intermitted Duty.
MX41
11.250.190

Your Cost
$149.00

ISKRA / Letrika/MAHLE
12 Volt Relay / Solenoid
300A Intermitted Duty.
Mounts on Pump Motors
(2) M10-1.5 Threaded Terminals
(2) 6.5mm Blade Terminals
11250190
ADR1305

ISKRA / Letrika/MAHLE 24 Volt Relay / Solenoid. 300A Intermitted Duty.
MX43
11.250.195

Your Cost
$185.00

ISKRA / Letrika/MAHLE
24 Volt Relay / Solenoid
300A Intermitted Duty.
Mounts on Pump Motors
(2) M10-1.5 Threaded Terminals
(2) 6.5mm Blade Terminals
11250195

Nippondenso 182800-2280 Intermittent Duty Relay.
182800-2280
Your Cost

$29.50

Denso 12 volts 4 Terminals
Insulated coil
Intermittent Duty Relay
M6-1.0 Threaded Battery
M6-1.0 Motor Studs
6.3mm Blade Terminal for Ignition,
Mounting Holes 6.6mm Wide
58.5mm Center to Center
Special Application Usage
Nippondenso 182800-2280


12 Volt Intermittent Duty Denso Replaces 182800-1570 and Honda 31204ZA0-003
T- 182800-1570
Your Cost

$28.50



12 volts
3 Terminals
Intermittent Duty
M6-1.0 Threaded Battery
M6-1.0 Motor Studs
6.3mm Blade Terminal for Ignition,
Used on Nippondenso Starters
Honda Small Engine Applications
Nippondenso Starter 128000-2750 , 128000-3400
References:
Denso 182800-1570
Honda 31204ZA0-003
89-96158 Mercury Marine Starter Relay

89-96158
Your Cost

$19.50

Mercury Marine
Outboard Motor Starter Relay
12 Volt
4 Terminal
Insulated Base.
1/4-20 Battery and Motor Terminals.
8-32 Ground and Switch Terminals

AMF / 12 Volt  Universal Small Starter Applications .

T-22000
12 Volt Relay
Your Cost
$ 14.00

12 Volt Relay
Grounded Base
Vertical Mounting Bracket
1 = 5/16- Motor Stud,
1 = 1/4-20 Battery Stud
1 = 8-32 Switch Terminal

Application: AMF
Small Starter Applications, Riding Lawn Mowers.

AMF / 12 Volt  Universal Small Starter Applications .

T-22007
12 Volt Relay
Your Cost
$ 14.00

12 Volt Relay
Grounded Base
Vertical Mounting Bracket
1 = 1/4-20 Motor Stud,
1 = 1/4-20 Battery Stud
1 = 8-32 Switch Terminal

Application: AMF
Small Starter Applications, Riding Lawn Mowers.

Click Here
For More Information

Murphy Engine Safety System Push Button Relay Switch 12-36 Volt Shuts Down Engine When Connected Gauges Reach Set Limit
117PH
Your Cost
$105.50


Murphy Engine Safety System Push Button Relay Switch
Push to Reset,
Shuts Down Engine When Connected Murphy Gauges Reach Set Limit
12-36 Volt
For Distributor Ignition & Diesel Engines
14A Fuse Attached

F.W. Murphy 518APH12V Murphy Engine Safety System Push Button Relay Switch 12-36 Volt Shuts Down Engine When Connected Gauges Reach Set Limit
518APH12
Your Cost
$105.50

F.W. Murphy
12 Volt
10 Amp
SPST
Push Button Reset

Shuts Down Engine When Connected Gauge Reaches Set Limit

25700147, 518APH12V


518PH112
Your Cost
$105.50

F.W. Murphy
12 Volt
10 Amp
SPST
Push Button Reset

Shuts Down Engine When Connected Gauge Reaches Set Limit

Distributor, Ignition & Diesel Engines
25700287, 518PH12V



Trombetta Push Button Switch  26240C1 12/24 Volt 400 Amp Inrush
26240
Your Cost
$35.50

Trombetta Push Button Switch
12/24V 80 Amp 400 Amp Inrush
(2) 6.3mm ID Unthreaded Mounting Ears
Lift Gate Motors,
Material Handling
Hydraulic Pump Motors
Replaces Trombetta 26240C1,26240-1, 26240-2, 26240-3, 26240-4, 26240-5, 26240-6, 26240-7, 26240-8, 26240-9, 26240-10

Monarch Applications  Vendor 26763
26763
Your Cost
$62.50

Special Push Button Switch
Monarch Hydraulic Pump Motors.
Supplier: OEM(s): Monarch
Schematic: SPST
2 Terminals
Momentary: Yes
Weatherized: No
Normally Open Application:
Monarch Applications Reference Numbers: Miscellaneous Vendor Numbers
26763 , 267630, 267630A, 267630-AH
Trombetta 19832 , 19832-000
NLP BPL2250 Monarch 03416

12 Volt Monarch Applications  Vendor 267635A, Replaces 26763-5
267635A
Your Cost
$122.50

Special Push Button Switch
Trombetta Pump Motor Switch.
Supplier: OEM(s): Monarch
Schematic: SPST
2 Terminals 5/16-24 Studs
Momentary: Yes
Weatherized: No
Normally Open Application:
Monarch Applications
Trombetta numbers
26763-1, 26763-6, 267635, 26763-5




Back To Top Of Page
Intermittent Duty / Momentary Relays
Starter Relays 6 Volt & 12 Volt
6 volt Ford Starters And Farm Tractor 2N, 8N & 9N
7-1023

7-1023
Ford Tractor Starter Relay
For Models 2N, 8N & 9N
6 volt
3 Terminals
Intermittent Duty
Copper Contacts,
Ground Activated
Application: Ford Starters on Farm Tractor
2N, 8N & 9N
Replaces:
SW218 8N11450 SW355

Your Cost
$
15.75
12 volt For Ford Starters And Farm Tractor 2N, 8N & 9N
7-1023-12V

7-1023-12V
12 Volt Ford Tractor Starter Relay
For Models 2N, 8N & 9N
12 volt
3 Terminals
Intermittent Duty
Copper Contacts,
Ground Activated
Application: Ford Starters on Farm Tractor
2N, 8N & 9N
Your Cost
$
16.50

Early Model Ford Products.
7-1025

7-1025
Solenoid 12 Volt DC Starter Relay.
Intermittent Duty
4-Terminal Used On: Early Model Ford Products.
Also can be used as a hard start starter relay.
Battery Term. 5/16-18
Motor Term. 5/16-18
Switch Term. 10-32 Post
Relay Term. 10-32 Post
7-1025
Your Cost
$15.75

Later Model Ford Products Suppression Diode
7-1034

7-1034
Solenoid 12 Volt DC Starter Relay.
4-Terminal Used On: Later Model Ford Products, Some Construction Equipment.
Intermittent Duty
Battery Term. 5/16-18
Motor Term. 5/16-18
Switch Term. 10-32 Post
Relay Terminal 10-32 Post
Features: - Suppression Diode
Can Replace FORD, D8VY11450A, E5AZ11450A, E7VF11450A, E8TZ11450B, SW1533,
Ametek / Prestolite 15-436

Your Cost
$17.00

Later Model Ford Products Suppression Diode
7-1035

7-1035
Solenoid 12 Volt DC Starter Relay.
3-Terminal Used On: Later Model Ford Products, Some Construction Equipment.
Intermittent Duty
Battery Term. 5/16-18
Motor Term. 5/16-18
Switch Term. 10-32 Post
Features: - Suppression Diode
7-1035 , SW1951
Can Replace 15-450 SAZ4201EA , SAZ-4102EA Ametek / Prestolite

Your Cost
$17.00



Series Parallel Switches 12 Volt to 24 & 32 Volt Starter Relays & Solenoids


Series Parallel Switch

Heavy Duty 7 Terminal Series Parallel Switch
Triple Stage, 3 Collar
Used on Marine & Industrial Applications.
Voltage: 12/24
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
45 Amps Maximum Charge Back Circuit
"Must use 50 amp Circuit Breaker on the #5 Terminal "
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Replaces Delco Remy Relay 1119844
Cummins 3603871RX
IHC 181907H1
In Some Applications May Be Used To Replace The Leece Neville 5155S
Made In USA
Click Here For More Details







Your Cost
$210.00

Click On Image For
More Details
Series Parallel Switch 3 Stage Heavy Duty Relays.

Made In USA
1119844-6V


6 Volt Series Parallel Switch

Heavy Duty 7 Terminal Series Parallel Switch
Triple Stage, 3 Collar
Used on Older Cars & Equipment
Start On 12 Volts & Keep Your Original 6 Volt Charging System.
Automotive & Industrial Applications.
Voltage: 6/12
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
45 Amps Maximum Charge Back Circuit

"Must use 50 amp Circuit Breaker on the #5 Terminal "
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Please Allow 7-10 Days To Build .
Made In USA
Click Here For More Details




Please Call
For Pricing


Series Parallel Switch

Heavy Duty 7 Terminal Series Parallel Switch
Double Stage, 2 Collar
Used on Marine & Industrial Applications.
Voltage: 12/24
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
45 Amps Maximum Charge Back Circuit
"Must use 50 amp Circuit Breaker on the #3 & 5 Terminals "

Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Replaces Delco Remy Relay 1119845
Caterpillar 9L4590
Cummins 3603872RX
Click Here For More Details




Your Cost
$175.00

Click On Image For
More Details

1119845-6V  6 / 12 Volt Series Parallel Switch.
Made In USA
1119845-6V

6 Volt Series Parallel Switch

Heavy Duty 7 Terminal Series Parallel Switch
Double Stage, 2 Collar
Used on Older Cars & Equipment
Start On 12 Volts & Keep Your Original 6 Volt Charging System.
Automotive & Industrial Applications.

Voltage: 6/12
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
45 Amps Maximum Charge Back Circuit
"Must use 50 amp Circuit Breaker on the #3 & 5 Terminals "
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Please Allow 7-10 Days To Build .
Click Here For More Details



Please Call
For Pricing


Heavy Duty 4 Terminal Relay
Used on Marine & Industrial Applications.
Caterpillar,GMC, Detroit Diesel ,Allis Chamers,Ingersoll Rand & more.
Voltage: 12/24
This Relay Can Be Used With Either 12 or 24 Volt Cranking Circuits.
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Replaces Delco Remy Relay 1119865
Caterpillar Numbers 5F7739, 6L2507, 7M4291, 7N3621 E30154
May Be Used To Replace The Leece Neville 4912 Relay & 4912S Relay & 4924SD Relays.

To View A Drawing Of These Relays Click Here




12/24 Volt
$130.00

Click On Image For
More Details

Heavy Duty Relays 500 Amp Continuous Duty Rating.
Made In USA
1119865CD


Heavy Duty 4 Terminal Relay
Used on Marine & Industrial Applications.
Caterpillar, GMC , Detroit Diesel
, Allis Chamers,Ingersoll Rand & more.
Voltage: 12
Coil: Insulated Circuit
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Rated at 500 Amp Extended Duty .
1500 Amp intermittent Duty
"This Relays Need To Be Mounted In A Well Ventilated Area."
If Not Mounted In A Well Ventilated Area Can Suffer Internal Coil Damage
"These Relays Surface Temperature may reach 200 Degrees"

* CD (Extended Duty Rated)

Some Extended Duty Applications May Require Use of
The SCM ( Solenoid Controller Module).

To View A Drawing Of These Relays Click Here







12 Volt CD*
$185.00


Click On Image For
More Details

Heavy Duty Relays 1500 Amp Intermittent Duty Rating.
Made In USA
1119866
24 Volt

Heavy Duty 4 Terminal Relay
Used on Marine & Industrial Applications.
Caterpillar,GMC, Detroit Diesel ,Allis Chamers,Ingersoll Rand & more.
Voltage:24
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Replaces Delco Remy Relay 1119866
To View A Drawing Of These Relays Click Here




24 Volt
$170.00

Click On Image For
More Details

Heavy Duty Relays 500 Amp Continuous Duty Rating.
Made In USA
1119866CD


Heavy Duty 4 Terminal Relay
Used on Marine & Industrial Applications.
Caterpillar, GMC , Detroit Diesel
, Allis Chamers,Ingersoll Rand & more.
Voltage: 24
Coil: Insulated Circuit
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Rated at 500 Amp Extended Duty.
With the SCM Solenoid Control Module You Can use in a Continuous Duty,
1500 Amp intermittent Duty
.
"This Relays Need To Be Mounted In A Well Ventilated Area."
If Not Mounted In A Well Ventilated Area Can Suffer Internal Coil Damage
"These Relays Surface Temperature may reach 200 Degrees"

* CD (Extended Duty Rated)
Some Extended Duty Applications May Require Use of
The SCM ( Solenoid Controller Module).

To View A Drawing Of These Relays Click Here






24 Volt CD*
$225.00

Click On Image For
More Details

Heavy Duty Extended Use 24 Volt Relay 800 Amp Continuous Duty Rating.
Made In USA
1119866ECD


Heavy Duty 4 Terminal Relay
Used on Marine & Industrial Applications.
Caterpillar, GMC , Detroit Diesel
, Allis Chamers,Ingersoll Rand & more.
Voltage: 24
Coil: Insulated Circuit
Contacts : Extra Heavy Duty Silver Contact Disk
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Rated at 800 Amp Extended Duty.
With the SCM Solenoid Control Module You Can use in a Continuous Duty,
1500 Amp intermittent Duty.
"This Relays Need To Be Mounted In A Well Ventilated Area."
If Not Mounted In A Well Ventilated Area Can Suffer Internal Coil Damage
"These Relays Surface Temperature may reach 200 Degrees"

* ECD (Extended Duty )
Some Extended Duty Applications May Require Use of
The SCM ( Solenoid Controller Module).

To View A Drawing Of These Relays Click Here






24 Volt ECD*
$235.00


Heavy Duty 4 Terminal Relay
Used on Marine & Industrial Applications.
Caterpillar,GMC, Detroit Diesel
Voltage: 32
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Replaces Delco Remy Relay's 1119867, 1118193, 1119959
To View A Drawing Of These Relays Click Here




32 Volt
$185.00





The SCM Solenoid Control Module
Allows The Use of Any of The 1119865CD / 1119866CD Family of Relays
To be be used In a Extended Condition Use Operation.
This Module Monitors The Voltage being applied to the Relay at all times.
When Heavy Amperage is needed the SCM will apply more current to the hold in coil.
When the Amperages decreases the SCM will reduce the current being applied to the solenoid thus giving longer life to the relay and reduces the current draw of the solenoid.






2-40 Volt DC
$255.00


Series Parallel Switch
Heavy Duty 8 Terminal Series Parallel Switch
2 Normally Closed Circuits
1 Normally Open Circuit
Used on Marine & Industrial Applications.
12/24 Volt Series Parallel Switch
Can be used to Control 24 Volt Bow Thrusters on large Boats a 1119865CD may be required .
Extended Duty Applications Will Require Use of The SCM ( Solenoid Controller Module).
Cranking Systems on 24 Volt & Charging on 12 Volt
Voltage: 12/24
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
With the SCM Solenoid Control Module You Can use in a Extended Duty,
175 Amp Charging Circuit
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32
Can Be Used To Replace Leece Neville 5155S








Please Call For Pricing


Series Parallel Switch
Heavy Duty 8 Terminal Series Parallel Switch
2 Normally Closed Circuits
1 Normally Open Circuit
Used on Marine & Industrial Applications.
Can Be Used For Starting System For Turbine Engine
24/48 Volt Series Parallel Switch
Cranking at 48 Volt & Charging on 24 Volt
Can be used to Control 48 Volt Bow Thrusters on large Boats a 1119866CD may be required .
Extended Duty Applications Will Require Use of The SCM ( Solenoid Controller Module).
Voltage: 24/48
Coil: Insulated Circuit
Rated at 1500 amps Intermittent Duty.
With the SCM Solenoid Control Module You Can use in a Extended Duty,
175 Amp Charging Circuit
Contacts : Silver
Relay Battery Terminal Studs 3/8 x 16
Coil Terminal studs 10x32







Please Call For Pricing


3A-105 12 Volt Solenoid & Emergency Start Handle

Fire Pump Starter Solenoid
Specifications: Maximum Coil Current 12V = 6A Max.
Contact Breakaway Current: 2000A DC
Contact Voltage: 30V DC (All Models)
Intermittent Duty Cycle: 15 seconds On / 15 seconds Off = 1 Cycle
Contact Rolling Current: 1000A DC
3 cycles Max then 1 hour Off
.
UL Certified: UL 218A, Battery Contactor's for Use in Diesel Engines Driving Centrifugal Fire Pumps.
CSA C22.2 No 263, Fire Pump Controllers.
May Replace Metron 1804A , 1804A-12 & DUMORE 12 VOLT UNITS
Made In USA

3B-105 24 Volt Solenoid & Emergency Start Handle
Fire Pump Starter Solenoid
Specifications: Maximum Coil Current 12V = 6A Max.
Contact Breakaway Current: 2000A DC
Contact Voltage: 30V DC (All Models)
Intermittent Duty Cycle: 15 seconds On / 15 seconds Off = 1 Cycle
Contact Rolling Current: 1000A DC
3 cycles Max then 1 hour Off
.
UL Certified: UL 218A, Battery Contactor's for Use in Diesel Engines Driving Centrifugal Fire Pumps.
CSA C22.2 No 263, Fire Pump Controllers.
May Replace Metron& DUMORE 24 VOLT UNITS
Made In USA








Your Cost
$925.00

Back To Top Of Page

Click Here To Return to The  Electrical Area.

Click Here To Return To The Home Page.

Texas Industrial Electric Co.
San Antonio Texas
Phone 210.654.4075
Fax 210.599.2843


We accept American Express,  Master Card, Visa & Discover
We accept American Express,  Master Card, Visa & Discover
We accept American Express,  Master Card, Visa & Discover
We accept American Express,  Master Card, Visa & Discover

God Bless America. E-mail : TIE@TexasIndustrialElectric.com God Bless Texas
